8.1.2 Terminals
Items supplied, terminal kits
•
Terminal X1–X2: Each kit contains 3 terminal blocks, including labels for matching designations.
•
Terminal X3–X4: Each kit contains 3 terminal blocks, including labels for matching designations.
•
Terminal A+B: Each kit contains 3 terminal blocks, including labels for matching designations.
The spare part terminal kits support the following lters:
•
VLT
®
Advanced Harmonic Filter AHF 005 IP00.
•
VLT
®
Advanced Harmonic Filter AHF 005 IP20.
•
VLT
®
Advanced Harmonic Filter AHF 010 IP00.
•
VLT
®
Advanced Harmonic Filter AHF 010 IP20.
380–415 V
50 Hz
Terminals X1+X2 Terminals X3+X4 Terminals A+B
Current
rating
Ordering
number
Description
Ordering
number
Description
Ordering
number
Description
[A]
Mains input and output
terminals
Capacitor disconnect
terminals
Thermal switch
terminals
10 175U0258 WDU 6 600 V 50 A 175U0257 WDU 2.5 600 V 25 A 175U0257 WDU 2.5 600 V 25 A
14 175U0258 WDU 6 600 V 50 A 175U0257 WDU 2.5 600 V 25 A 175U0257 WDU 2.5 600 V 25 A
22 175U0259 WDU 10 600 V 65 A 175U0257 WDU 2.5 600 V 25 A 175U0257 WDU 2.5 600 V 25 A
29 175U0259 WDU 10 600 V 65 A 175U0257 WDU 2.5 600 V 25 A 175U0257 WDU 2.5 600 V 25 A
34 175U0260 WDU 16 600 V 85 A 175U0259 WDU 10 600 V 65 A 175U0257 WDU 2.5 600 V 25 A
40 175U0260 WDU 16 600 V 85 A 175U0259 WDU 10 600 V 65 A 175U0257 WDU 2.5 600 V 25 A
55 175U0260 WDU 16 600 V 85 A 175U0259 WDU 10 600 V 65 A 175U0257 WDU 2.5 600 V 25 A
66 175U0261 WDU 35 1000 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
82 175U0261 WDU 35 1000 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
96 175U0262 WDU 50N 600 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
133 175U0262 WDU 50N 600 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
171 175U0263 WFF70N/AH 1000 V 183 A 175U0261 WDU 35 1000 V 150 A 175U0257 WDU 2.5 600 V 25 A
204 175U0263 WFF70N/AH 1000 V 183 A 175U0261 WDU 35 1000 V 150 A 175U0257 WDU 2.5 600 V 25 A
251 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
304 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
325 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
381 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
480 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
Table 8.6 Terminal Kits, 380–415 V 50 Hz
Spare Parts Design Guide
MG80C502 Danfoss A/S © 10/2016 All rights reserved. 137
