Danfoss VLT AHF 005

7.2.7 Mechanical Dimensions
380–415 V
50 Hz
AHF 005
IP00
AHF 005
IP20
Current
rating
Dimensions Weight
Enclosure
size
Dimensions Weight Enclosure size
[A]
Height
[mm (in)]
Width
[mm (in)]
Depth
[mm (in)]
[kg (lb)] IP00
Height
[mm (in)]
Width
[mm (in)]
Depth
[mm (in)]
[kg (lb)] IP20
10 323 (12.7) 196 (7.7) 205 (8.1) 16 (35) X1 IP00 323 (12.7) 196 (7.7) 205 (8.1) 18 (40) X1 IP20 if1
14 323 (12.7) 196 (7.7) 205 (8.1) 17 (38) X1 IP00 346 (13.6) 196 (7.7) 205 (8.1) 20 (44) X1 IP20 ef1
22 433 (17) 238 (9.4) 248 (9.8) 25 (55) X2 IP00 455 (17.9) 238 (9.4) 248 (9.8) 30 (66) X2 IP20 ef1
29 433 (17) 238 (9.4) 248 (9.8) 30 (66) X2 IP00 455 (17.9) 238 (9.4) 248 (9.8) 34 (75) X2 IP20 ef1
34 590 (23.2) 378 (14.9) 245 (9.6) 45 (99) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 52 (115) X3 IP20 if1
40 590 (23.2) 378 (14.9) 245 (9.6) 46 (101) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 53 (117) X3 IP20 if1
55 590 (23.2) 378 (14.9) 245 (9.6) 51 (112) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 58 (128) X3 IP20 if1
66 620 (24.4) 378 (14.9) 338 (13.3) 68 (150) X4 IP00 620 (24.4) 378 (14.9) 338 (13.3) 76 (168) X4 IP20 if1
82 620 (24.4) 378 (14.9) 338 (13.3) 89 (196) X4 IP00 644 (25.4) 378 (14.9) 338 (13.3) 98 (216) X4 IP20 ef1
96 737 (29) 418 (16.5) 333 (13.1) 94 (207) X5 IP00 752 (29.6) 418 (16.5) 333 (13.1) 104 (229) X5 IP20 ef1
133 737 (29) 418 (16.5) 333 (13.1) 96 (212) X5 IP00 752 (29.6) 418 (16.5) 333 (13.1) 106 (234) X5 IP20 ef1
171 767 (30.2) 418 (16.5) 405 (15.9) 115 (254) X6 IP00 789 (31.1) 418 (16.5) 405 (15.9) 126 (278) X6 IP20 ef1
204 767 (30.2) 418 (16.5) 405 (15.9) 124 (273) X6 IP00 789 (31.1) 418 (16.5) 405 (15.9) 135 (298) X6 IP20 ef1
251 949 (37.4) 468 (18.4) 451 (17.8) 159 (351) X7 IP00 949 (37.4) 468 (18.4) 451 (17.8) 172 (379) X7 IP20 if1
304 949 (37.4) 468 (18.4) 451 (17.8) 193 (425) X7 IP00 949 (37.4) 468 (18.4) 451 (17.8) 206 (454) X7 IP20 if1
325 949 (37.4) 468 (18.4) 515 (20.3) 208 (459) X8 IP00 949 (37.4) 468 (18.4) 515 (20.3) 221 (487) X8 IP20 if1
381 949 (37.4) 468 (18.4) 515 (20.3) 214 (472) X8 IP00 966 (38) 468 (18.4) 515 (20.3) 230 (507) X8 IP20 ef1
480 949 (37.4) 468 (18.4) 515 (20.3) 253 (558) X8 IP00 966 (38) 468 (18.4) 515 (20.3) 272 (600) X8 IP20 ef1
Table 7.9 380–415 V, 50 Hz, AHF 005
380–415 V
50 Hz
AHF 010
IP00
AHF 010
IP20
Current
rating
Dimensions Weight
Enclosure
size
Dimensions Weight Enclosure size
[A]
Height
[mm (in)]
Width
[mm (in)]
Depth
[mm (in)]
[kg (lb)] IP00
Height
[mm (in)]
Width
[mm (in)]
Depth
[mm (in)]
[kg (lb)] IP20
10 323 (12.7) 196 (7.7) 205 (8.1) 11.5 (25.4) X1 IP00 323 (12.7) 196 (7.7) 205 (8.1) 13.5 (29.8) X1 IP20 if1
14 323 (12.7) 196 (7.7) 205 (8.1) 13 (29) X1 IP00 346 (13.6) 196 (7.7) 205 (8.1) 16.3 (35.9) X1 IP20 ef1
22 433 (17) 238 (9.4) 248 (9.8) 17 (38) X2 IP00 433 (17) 238 (9.4) 248 (9.8) 22 (49) X2 IP20 if1
29 433 (17) 238 (9.4) 248 (9.8) 21 (46) X2 IP00 433 (17) 238 (9.4) 248 (9.8) 25 (55) X2 IP20 if1
34 590 (23.2) 378 (14.9) 245 (9.6) 26 (57) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 33 (73) X3 IP20 if1
40 590 (23.2) 378 (14.9) 245 (9.6) 30 (66) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 37 (82) X3 IP20 if1
55 590 (23.2) 378 (14.9) 245 (9.6) 32 (71) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 39 (86) X3 IP20 if1
66 620 (24.4) 378 (14.9) 338 (13.3) 36 (79) X4 IP00 620 (24.4) 378 (14.9) 338 (13.3) 44 (97) X4 IP20 if1
82 620 (24.4) 378 (14.9) 338 (13.3) 47 (104) X4 IP00 644 (25.4) 378 (14.9) 338 (13.3) 56 (123) X4 IP20 ef1
96 737 (29) 418 (16.5) 333 (13.1) 52 (115) X5 IP00 752 (29.6) 418 (16.5) 333 (13.1) 62 (137) X5 IP20 ef1
133 737 (29) 418 (16.5) 333 (13.1) 62 (137) X5 IP00 752 (29.6) 418 (16.5) 333 (13.1) 74 (164) X5 IP20 ef1
171 767 (30.2) 418 (16.5) 405 (15.9) 74 (163) X6 IP00 767 (30.2) 418 (16.5) 405 (15.9) 85 (187) X6 IP20 if1
204 767 (30.2) 418 (16.5) 405 (15.9) 91 (201) X6 IP00 767 (30.2) 418 (16.5) 405 (15.9) 102 (225) X6 IP20 if1
251 949 (37.4) 468 (18.4) 451 (17.8) 106 (234) X7 IP00 949 (37.4) 468 (18.4) 451 (17.8) 119 (262) X7 IP20 if1
304 949 (37.4) 468 (18.4) 451 (17.8) 123 (271) X7 IP00 949 (37.4) 468 (18.4) 451 (17.8) 136 (300) X7 IP20 if1
325 949 (37.4) 468 (18.4) 451 (17.8) 129 (284) X7 IP00 949 (37.4) 468 (18.4) 451 (17.8) 142 (313) X7 IP20 if1
381 949 (37.4) 468 (18.4) 451 (17.8) 147 (324) X7 IP00 949 (37.4) 468 (18.4) 451 (17.8) 163 (359) X7 IP20 if1
480 949 (37.4) 468 (18.4) 515 (20.3) 186 (410) X8 IP00 966 (38) 468 (18.4) 515 (20.3) 205 (422) X8 IP20 ef1
Table 7.10 380–415 V, 50 Hz, AHF 010
