7 Specications
7.1 General Specications
7.1.1 General Technical Data
Supply voltage 380 V/60 Hz
400 V/50 Hz
460 V/60 Hz
600 V/60 Hz
690 V/50 Hz
Nominal supply voltages 380–415 V/60 Hz
380–415 V/50 Hz
440–480 V/60 Hz
600 V/60 Hz
500–690 V/50 Hz
Supply voltage tolerance
±10%
Tolerances of the actual supply voltage 342–456 V/60 Hz
342–456 V/50 Hz
396–528 V/60 Hz
540–660 V/60 Hz
450–759 V/50 Hz
Supply frequency tolerance +5% to -1.5%
Overload capability 160% for 60 s every 10 minutes
Eciency >0.98
THDi
1)
AHF 005 <5%
AHF 010 <10%
Cos φ of I
L
0.5 cap at 25% I
AHF,N
0.8 cap at 50% I
AHF,N
0.85 cap at 75% I
AHF,N
0.99 cap at 100% I
AHF,N
1.00 at 160% I
AHF,N
Power derating - temperature
5–45 °C (41–113 °F) without derating. 45–60 °C (113–140 °F) with derating 1.5% per °C. See
Illustration 7.1.
Power derating - altitude above sea level 1000 m (3280 ft) without derating. 1000–4000 m (3280–13123 ft) with derating 5% per 1000 m
(3280 ft).
Table 7.1 General Technical Data
1) THDi level is system level performance from the lter combined with the actual frequency converter.
NOTICE
The reduction of the low harmonic current emission to the rated THDi implies that the THDv of the non-inuenced
mains voltage is lower than 2%, and the ratio of short circuit power to installed load (R
SCE
) is above 66. Under these
conditions, the THDi of the mains current of the frequency converter is reduced to 10% or 5% (typical values at nominal
load). If these conditions are not or only partially fullled, a signicant reduction of the harmonic components can still
be achieved, but the rated THDi values may not be observed.
