Danfoss VLT AHF 005

X1 Mains 6mm
2
F1
F2
205 ± 2.5 mm [8.1± 0.1 in]
163 ± 1 mm [6.4± 0.04 in]
188 ± 1 mm [7.4± 0.04 in]
247.0 ± 2.0 mm [9.7± 0.1 in]
39 ± 2 mm [1.5± 0.1 in]
29 ± 2.0 mm [1.2 ± 0.1 in]
278 ± 2.5 mm [10.9± 0.1 in]
295 ± 2.5 mm [11.6± 0.1 in]
318 ± 2.5 mm [12.5± 0.1 in]
346 ± 2.5 mm [13.6± 0.1 in]
6.5 ± 1 mm [0.3± 0.04 in]
196 ± 2 mm [7.7± 0.1 in]
190 ± 2.0 mm [7.5± 0.1 in]
A/B Temperature 2.5mm
2
PE M6
X2 Drive 6mm
2
X3/X4 Capacitor disconnect 2.5mm
2
130BE368.10
Illustration 7.7 IP20 X1 External Fan 1
130BE369.10
Illustration 7.8 IP20 X1 External Fan 1, 3D View
Specications Design Guide
MG80C502 Danfoss A/S © 10/2016 All rights reserved. 61
7 7
