Danfoss VLT AHF 005 - Page 73

130BE406.10
157.0 ± mm [6.2 ±0.04 in]
50.0 ±2.5 mm [2.0 ±0.10 in]
54.3 ±2.5 mm [2.1 ±0.10 in]
157.0 ±1 mm [6.2 ±0.04 in]
9.0 ±1 mm [0.4 ±0.04 in]
240.0 ±1 mm [9.4 ±0.04 in]
X1 Mains 35 mm
2
X2 Drive 35 mm
2
A/B Temperature 2.5 mm
2
X3/X4 Capacitor disconnect 16 mm
2
PE M8
F1
F2
338 ±2.5 mm [13.3 ±0.1 in]
378.0 ±2.5 mm [14.9 ±0.10 in]
353.0 ±2.5 mm [13.9 ±0.10 in]
489 ±2.5 mm [19.3 ±0.10 in]
330.0 ±2.5 mm [13.0 ±0.10 in]
577.0 ±2.5 mm [22.7 ±0.10 in]
615.5 ±2.5 mm [24.2 ±0.10 in]
658.3 ±2.5 mm [25.9 ±0.10 in]
9.0 ±1 mm [0.4 ±0.004 in]
Illustration 7.27 IP20 X4 External Fan 2
130BE405.10
Illustration 7.28 IP20 X4 External Fan 2, 3D View
Specications Design Guide
MG80C502 Danfoss A/S © 10/2016 All rights reserved. 71
7 7
