X1 Mains 50 mm
2
X2 Drive 50 mm
2
A/B Temperature 2.5 mm
2
X3/X4 Capacitor disconnect 16 mm
2
405.3 ±2.5 mm [16.0 ±0.1 in]
PE M8
F1 F2
597.0 ±2.5 mm [23.5 ±0.1 in]
370.0 ±2.5 mm [14.6 ±0.1 in]
418.0 ± 2.5 mm [16.5 ± 0.10 in]
210.5 ±1.0 mm [8.3 ±0.04 in] 210.5 ±1.0 mm [8.3 ±0.04 in]240.0 ±1.0 mm [9.4 ±0.04 in]
94.3 ±2.5 mm [3.7 ±0.1 in]
9 ±1.0 mm [0.4 ±0.04 in]
9 ±1.0 mm [0.4 ±0.04 in]
393.0 ±2.5 mm [15.5 ±0.1 in]
685.0 ±2.5 mm [27.0 ±0.1 in]
767.3 ±2.5 mm [30.2 ±0.1 in]
130BE416.10
Illustration 7.39 IP20 X6 Internal Fan 2
130BE415.10
Illustration 7.40 IP20 X6 Internal Fan 2, 3D View
Specications Design Guide
