Danfoss VLT AHF 005 User Manual

1
Lower cover
2
Input power terminals (contactor option is shown)
3
DC terminals
4
Grounding bar
e30bu173.10
1
2
3
4
5
Illustration 57: Connection Points for Mains to Input Power Option (Enclosed Drive Configured With Power Options Cabinet)
1
Factory cables connecting contactor to drive input
terminals
2
Upper cover
3
Lower cover
4
Input power terminals (disconnect option is shown)
5
Grounding bar
5.8.3 Connecting the Drive Module to the Motor
Procedure
AQ262141314214en-000301 / 130R088098 | Danfoss A/S © 2021.11
Electrical Installation
VLT® HVAC Drive FC 102
Operating Guide
