Danfoss VLT AutomationDrive User Manual

Mains Supply 3 x 380 - 500 V AC (FC 302), 3 x 380 - 480V AC (FC 301)
FC 301/FC 302 P30K P37K P45K P55K P75K
High/ Normal Load
1)
HO NO HO NO HO NO HO NO HO NO
Typical Shaft output [kW] 30 37 37 45 45 55 55 75 75 90
Enclosure IP20 B4 C3 C3 C4 C4
Enclosure IP21 C1 C1 C1 C2 C2
Enclosure IP55, 66 C1 C1 C1 C2 C2
Output current
Continuous
(3 x 380-440V) [A]
61 73 73 90 90 106 106 147 147 177
Intermittent (60 sec.
overload)
(3 x 380-440V) [A]
91.5 80.3 110 99 135 117 159 162 221 195
Continuous
(3 x 441-500V) [A]
52 65 65 80 80 105 105 130 130 160
Intermittent (60 sec
overload)
(3 x 441-500V) [A]
78 71.5 97.5 88 120 116 158 143 195 176
Continuous kVA
(400V AC) [kVA]
42.3 50.6 50.6 62.4 62.4 73.4 73.4 102 102 123
Continuous kVA
(460V AC) [kVA]
51.8 63.7 83.7 104 128
Max. input current
Continuous
(3 x 380-440V) [A]
55 66 66 82 82 96 96 133 133 161
Intermittent (60 sec
overload)
(3 x 380-440V) [A]
82.5 72.6 99 90.2 123 106 144 146 200 177
Continuous
(3 x 441-500V) [A]
47 59 59 73 73 95 95 118 118 145
Intermittent (60 sec
overload)
(3 x 441-500V) [A]
70.5 64.9 88.5 80.3 110 105 143 130 177 160
Additional specifications
Max. cable size IP20, mains
and motor [mm
2
(AWG
2)
)]
35 (2) 50 (1) 50 (1) 95 (4/0) 150 (300mcm)
Max. cable size IP20, load
share and brake [mm
2
(AWG
2)
)]
35 (2) 50 (1) 50 (1) 95 (4/0) 95 (4/0)
Max. cable size, IP21/55/66
[mm
2
(AWG
2)
)]
90 (3/0) 90 (3/0) 90 (3/0) 120 (4/0) 120 (4/0)
Max cable size with mains
disconnect [mm
2
(AWG
2)
)]
35 (2) 70 (3/0) 150 (300mcm)
Estimated power loss
at rated max. load [W]
4)
570 698 697 843 891 1083 1022 1384 1232 1474
Weight,
enclosure IP21, IP55, 66 [kg]
45 45 45 65 65
Efficiency
4)
0.98 0.98 0.98 0.98 0.99
Specifications
VLT
®
AutomationDrive Operating
Instructions
MG.33.AJ.02 - VLT
®
is a registered Danfoss trademark 65
10 1
0

Danfoss VLT AutomationDrive Specifications

General

Supply Voltage	3 x 200-240 V ±10% 3 x 380-500 V ±10% 3 x 525-600 V ±10%
Enclosure	IP20
Output Power Range	0.25 kW - 1.5 MW
Communication Protocols	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit, Ground fault, Motor overload
Ambient Temperature Range	-10°C to +50°C (14°F to 122°F)
