Danfoss VLT AutomationDrive User Manual

Mains Supply 3 x 525 - 600V AC (FC 302 only)
FC 302 PK75 P1K1 P1K5 P2K2 P3K0 P4K0 P5K5 P7K5
Typical Shaft Output [kW] 0.75 1.1 1.5 2.2 3 4 5.5 7.5
Enclosure IP20, 21 A3 A3 A3 A3 A3 A3 A3 A3
Enclosure IP55 A5 A5 A5 A5 A5 A5 A5 A5
Output current
Continuous
(3 x 525-550V ) [A]
1.8 2.6 2.9 4.1 5.2 6.4 9.5 11.5
Intermittent
(3 x 525-550V ) [A]
2.9 4.2 4.6 6.6 8.3 10.2 15.2 18.4
Continuous
(3 x 551-600V ) [A]
1.7 2.4 2.7 3.9 4.9 6.1 9.0 11.0
Intermittent
(3 x 551-600V ) [A]
2.7 3.8 4.3 6.2 7.8 9.8 14.4 17.6
Continuous kVA (525 V AC) [kVA] 1.7 2.5 2.8 3.9 5.0 6.1 9.0 11.0
Continuous kVA (575V AC) [kVA] 1.7 2.4 2.7 3.9 4.9 6.1 9.0 11.0
Max. input current
Continuous
(3 x 525-600V) [A]
1.7 2.4 2.7 4.1 5.2 5.8 8.6 10.4
Intermittent
(3 x 525-600V) [A]
2.7 3.8 4.3 6.6 8.3 9.3 13.8 16.6
Additional specifications
Max. cable size
(mains, motor, brake)
[AWG]
2)
[mm
2
]
24 - 10 AWG
0.2 - 4 mm
2
24 - 10 AWG
0.2 - 4 mm
2
Estimated power loss
at rated max. load [W]
4)
35 50 65 92 122 145 195 261
Weight,
Enclosure IP20 [kg]
6.5 6.5 6.5 6.5 6.5 6.5 6.6 6.6
Weight,
enclosure IP55 [kg]
13.5 13.5 13.5 13.5 13.5 13.5 14.2 14.2
Efficiency
4)
0.97 0.97 0.97 0.97 0.97 0.97 0.97 0.97
Specifications
VLT
®
AutomationDrive Operating
Instructions
66 MG.33.AJ.02 - VLT
®
is a registered Danfoss trademark
100

Danfoss VLT AutomationDrive Specifications

General

Supply Voltage	3 x 200-240 V ±10% 3 x 380-500 V ±10% 3 x 525-600 V ±10%
Enclosure	IP20
Output Power Range	0.25 kW - 1.5 MW
Communication Protocols	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit, Ground fault, Motor overload
Ambient Temperature Range	-10°C to +50°C (14°F to 122°F)
