Danfoss VLT FC 100 Design Guide

Recommended max. fuse
FC 302
[kW]
Max.
prefuse
Bussmann
E52273
RK1/JDDZ
Bussmann
E4273
J/JDDZ
Bussmann
E4273
T/JDDZ
SIBA
E180276
RK1/JDDZ
LittelFuse
E81895
RK1/JDDZ
Ferraz-
Shawmut
E163267/E2137
RK1/JDDZ
Ferraz-
Shawmut
E2137
J/HSJ
11 30 A KTS-R-30 JKS-30 JKJS-30 5017906-030 KLS-R-030 A6K-30-R HST-30
15-18.5 45 A KTS-R-45 JKS-45 JJS-45 5014006-050 KLS-R-045 A6K-45-R HST-45
22 60 A KTS-R-60 JKS-60 JJS-60 5014006-063 KLS-R-060 A6K-60-R HST-60
30 80 A KTS-R-80 JKS-80 JJS-80 5014006-080 KLS-R-075 A6K-80-R HST-80
37 90 A KTS-R-90 JKS-90 JJS-90 5014006-100 KLS-R-090 A6K-90-R HST-90
45 100 A KTS-R-100 JKS-100 JJS-100 5014006-100 KLS-R-100 A6K-100-R HST-100
55 125 A KTS-R-125 JKS-125 JJS-125 2028220-125 KLS-150 A6K-125-R HST-125
75 150 A KTS-R-150 JKS-150 JJS-150 2028220-150 KLS-175 A6K-150-R HST-150
* UL compliance only 525-600V
Table 8.14 525-690V*, Frame Sizes B and C
FC 302
[kW]
Recommended
Drive External
Fuse
Bussmann PN
Rating Drive Internal
Option
Bussmann PN
Alternate
External
Bussmann PN
Alternate
External
Bussmann PN
Alternate
External
Siba PN
Alternate
External
Littlefuse PN
Alternate
External
Ferraz-
Shawmut PN
90 170M3017 315A, 700V 170M3018 FWH-300 JJS-300 2028220-315 L50-S-300 A50-P-300
110 170M3018 350A, 700V 170M3018 FWH-350 JJS-350 2028220-315 L50-S-350 A50-P-350
132 170M4012 400A, 700V 170M4016 FWH-400 JJS-400 206xx32-400 L50-S-400 A50-P-400
160 170M4014 500A, 700V 170M4016 FWH-500 JJS-500 206xx32-500 L50-S-500 A50-P-500
200 170M4016 630A, 700V 170M4016 FWH-600 JJS-600 206xx32-600 L50-S-600 A50-P-600
Table 8.15 380-480/500V, Frame Size D, Line Fuse
FC 302 [kW] Recommended Drive
External Fuse
Bussmann PN
Rating Drive Internal
Option
Bussmann PN
Alternate External
Siba PN
Alternate External
Ferraz-Shawmut PN
250 170M4017 700A, 700V 170M4017 20 610 32.700 6.9URD31D08A0700
315 170M6013 900A, 700V 170M6013 22 610 32.900 6.9URD33D08A0900
355 170M6013 900A, 700V 170M6013 22 610 32.900 6.9URD33D08A0900
400 170M6013 900A, 700V 170M6013 22 610 32.900 6.9URD33D08A0900
Table 8.16 380-480/500V, Frame Size E, Line Fuse
FC 302 [kW] Recommended Drive
External Fuse
Bussmann PN
Rating Drive Internal Option
Bussmann PN
Alternate Siba PN
450 170M7081 1600A, 700V 170M7082 20 695 32.1600
500 170M7081 1600A, 700V 170M7082 20 695 32.1600
560 170M7082 2000A, 700V 170M7082 20 695 32.2000
630 170M7082 2000A, 700V 170M7082 20 695 32.2000
710 170M7083 2500A, 700V 170M7083 20 695 32.2500
800 170M7083 2500A, 700V 170M7083 20 695 32.2500
Table 8.17 380-480/500V, Frame Size F, Line Fuse
Electrical Installation FC 300 Design Guide
198 MG.33.BD.02 - VLT
®
is a registered Danfoss trademark
88
