Danfoss VLT FC 100 Design Guide

FC 302 [kW] Drive Internal Bussmann PN Rating Alternate Siba PN
450 170M8611 1100A, 1000V 20 781 32.1000
500 170M8611 1100A, 1000V 20 781 32.1000
560 170M6467 1400A, 700V 20 681 32.1400
630 170M6467 1400A, 700V 20 681 32.1400
710 170M8611 1100A, 1000V 20 781 32.1000
800 170M6467 1400A, 700V 20 681 32.1400
Table 8.18 380-480/500V, Frame Size F, Inverter Module DC Link Fuses
FC 302 [kW] Recommended Drive
External Fuse
Bussmann PN
Rating Drive Internal
Option
Bussmann PN
Alternate External
Siba PN
Alternate External
Ferraz-Shawmut PN
37 170M3013 125A, 700V 170M3015 2061032,125 6.9URD30D08A0125
45 170M3014 160A, 700V 170M3015 2061032,16 6.9URD30D08A0160
55 170M3015 200A, 700V 170M3015 2061032,2 6.9URD30D08A0200
75 170M3015 200A, 700V 170M3015 2061032,2 6.9URD30D08A0200
90 170M3016 250A, 700V 170M3018 2061032,25 6.9URD30D08A0250
110 170M3017 315A, 700V 170M3018 2061032,315 6.9URD30D08A0315
132 170M3018 350A, 700V 170M3018 2061032,35 6.9URD30D08A0350
160 170M4011 350A, 700V 170M5011 2061032,35 6.9URD30D08A0350
200 170M4012 400A, 700V 170M5011 2061032,4 6.9URD30D08A0400
250 170M4014 500A, 700V 170M5011 2061032,5 6.9URD30D08A0500
315 170M5011 550A, 700V 170M5011 2062032,55 6.9URD32D08A0550
Table 8.19 525-690V, Frame Size D, Line Fuse
FC 302 [kW]
Recommended Drive
External Fuse
Bussmann PN
Rating Drive Internal
Option
Bussmann PN
Alternate External
Siba PN
Alternate External
Ferraz-Shawmut PN
355 170M4017 700A, 700V 170M4017 20 610 32.700 6.9URD31D08A0700
400 170M4017 700A, 700V 170M4017 20 610 32.700 6.9URD31D08A0700
500 170M6013 900A, 700V 170M6013 22 610 32.900 6.9URD33D08A0900
560 170M6013 900A, 700V 170M6013 22 610 32.900 6.9URD33D08A0900
Table 8.20 525-690V, Frame Size E, Line Fuse
FC 302 [kW]
Recommended Drive
External Fuse
Bussmann PN
Rating Drive Internal Option
Bussmann PN
Alternate Siba PN
630 170M7081 1600A, 700V 170M7082 20 695 32.1600
710 170M7081 1600A, 700V 170M7082 20 695 32.1600
800 170M7081 1600A, 700V 170M7082 20 695 32.1600
900 170M7081 1600A, 700V 170M7082 20 695 32.1600
1000 170M7082 2000A, 700V 170M7082 20 695 32.2000
1200 170M7083 2500A, 700V 170M7083 20 695 32.2500
Table 8.21 525-690V, Frame Size F, Line Fuse
Electrical Installation FC 300 Design Guide
MG.33.BD.02 - VLT
®
is a registered Danfoss trademark 199
8 8
