FC 302 [kW] Drive Internal Bussmann PN Rating Alternate Siba PN
630 170M8611 1100A, 1000V 20 781 32.1000
710 170M8611 1100A, 1000V 20 781 32.1000
800 170M8611 1100A, 1000V 20 781 32.1000
900 170M8611 1100A, 1000V 20 781 32.1000
1000 170M8611 1100A, 1000V 20 781 32.1000
1200 170M8611 1100A, 1000V 20 781 32.1000
Table 8.22 525-690V, Frame Size F, Inverter Module DC Link Fuses
*170M fuses from Bussmann shown use the -/80 visual indicator, -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of
the same size and amperage may be substituted for external use
**Any minimum 500V UL listed fuse with associated current rating may be used to meet UL requirements.
Supplementary fuses
Frame size Bussmann PN* Rating
D, E and F KTK-4 4 A, 600V
Table 8.23 SMPS Fuse
Size/Type Bussmann PN* LittelFuse Rating
P90K-P250, 380-500V KTK-4 4 A, 600V
P37K-P400, 525-690V KTK-4 4 A, 600V
P315-P800, 380-500V KLK-15 15A, 600V
P500-P1M2, 525-690V KLK-15 15A, 600V
Table 8.24 Fan Fuses
Size/Type
Bussmann PN* Rating Alternative Fuses
2.5-4.0 A Fuse P450-P800, 380-500V LPJ-6 SP or SPI 6 A, 600V Any listed Class J Dual
Element, Time Delay, 6A
P630-P1M2, 525-690V LPJ-10 SP or SPI 10 A, 600V Any listed Class J Dual
Element, Time Delay, 10 A
4.0-6.3 A Fuse P450-P800, 380-500V LPJ-10 SP or SPI 10 A, 600V Any listed Class J Dual
Element, Time Delay, 10 A
P630-P1M2, 525-690V LPJ-15 SP or SPI 15 A, 600V Any listed Class J Dual
Element, Time Delay, 15 A
6.3 - 10 A Fuse P450-P800600HP-1200HP,
380-500V
LPJ-15 SP or SPI 15 A, 600V Any listed Class J Dual
Element, Time Delay, 15 A
P630-P1M2, 525-690V LPJ-20 SP or SPI 20 A, 600V Any listed Class J Dual
Element, Time Delay, 20A
10 - 16 A Fuse P450-P800, 380-500V LPJ-25 SP or SPI 25 A, 600V Any listed Class J Dual
Element, Time Delay, 25 A
P630-P1M2, 525-690V LPJ-20 SP or SPI 20 A, 600V Any listed Class J Dual
Element, Time Delay, 20 A
Table 8.25 Manual Motor Controller Fuses
Frame size
Bussmann PN* Rating Alternative Fuses
F LPJ-30 SP or SPI 30 A, 600V Any listed Class J Dual Element, Time
Delay, 30A
Table 8.26 30 A Fuse Protected Terminal Fuse
Frame size
Bussmann PN* Rating Alternative Fuses
F LPJ-6 SP or SPI 6 A, 600V Any listed Class J Dual Element, Time
Delay, 6A
Table 8.27 Control Transformer Fuse
Electrical Installation FC 300 Design Guide
200 MG.33.BD.02 - VLT
®
is a registered Danfoss trademark
