Danfoss VLT FC 100 Design Guide

Frame size Bussmann PN* Rating
F GMC-800MA 800 mA, 250V
Table 8.28 NAMUR Fuse
Frame size Bussmann PN* Rating Alternative Fuses
F LP-CC-6 6 A, 600 V Any listed Class CC, 6 A
Table 8.29 Safety Relay Coil Fuse with PILZ Relay
The fuses below are suitable for use on a circuit capable of
delivering 100,000 Arms (symmetrical), 240V, or 480V, or
500V, or 600V depending on the drive voltage rating. With
the proper fusing the drive Short Circuit Current Rating
(SCCR) is 100,000 Arms.
Power size Frame Rating Bussmann
Spare
Bussmann
Est. Fuse Power Loss [W]
FC-302 Size Voltage (UL) Amperes P/N P/N 400V 460V
P250T5 F8/F9 700 700 170M4017 176F8591 25 19
P315T5 F8/F9 700 700 170M4017 176F8591 30 22
P355T5 F8/F9 700 700 170M4017 176F8591 38 29
P400T5 F8/F9 700 700 170M4017 176F8591 3500 2800
P450T5 F10/F11 700 900 170M6013 176F8592 3940 4925
P500T5 F10/F11 700 900 170M6013 176F8592 2625 2100
P560T5 F10/F11 700 900 170M6013 176F8592 3940 4925
P630T5 F10/F11 700 1500 170M6018 176F8592 45 34
P710T5 F12/F13 700 1500 170M6018 176F9181 60 45
P800T5 F12/F13 700 1500 170M6018 176F9181 83 63
Table 8.30 Line Fuses, 380-500V
Power size Frame Rating Bussmann
Spare
Bussmann
Est. Fuse Power Loss [W]
FC-302 Size Voltage (UL) Amperes P/N P/N 600V 690V
P355T7 F8/F9 700 630 170M4016 176F8335 13 10
P400T7 F8/F9 700 630 170M4016 176F8335 17 13
P500T7 F8/F9 700 630 170M4016 176F8335 22 16
P560T7 F8/F9 700 630 170M4016 176F8335 24 18
P630T7 F10/F11 700 900 170M6013 176F8592 26 20
P710T7 F10/F11 700 900 170M6013 176F8592 35 27
P800T7 F10/F11 700 900 170M6013 176F8592 44 33
P900T7 F12/F13 700 1500 170M6018 176F9181 26 20
P1M0T7 F12/F13 700 1500 170M6018 176F9181 37 28
P1M2T7 F12/F13 700 1500 170M6018 176F9181 47 36
Table 8.31 Line Fuses, 525-690V
Size/Type
Bussmann PN* Rating Siba
P450 170M8611 1100 A, 1000 V 20 781 32.1000
P500 170M8611 1100 A, 1000 V 20 781 32.1000
P560 170M6467 1400 A, 700 V 20 681 32.1400
P630 170M6467 1400 A, 700 V 20 681 32.1400
P710 170M8611 1100 A, 1000 V 20 781 32.1000
P800 170M6467 1400 A, 700 V 20 681 32.1400
Table 8.32 Inverter module DC Link Fuses, 380-500V
Electrical Installation FC 300 Design Guide
MG.33.BD.02 - VLT
®
is a registered Danfoss trademark 201
8 8
