Danfoss VLT FC 100 Design Guide

Size/Type Bussmann PN* Rating Siba
P630 170M8611 1100 A, 1000 V 20 781 32. 1000
P710 170M8611 1100 A, 1000 V 20 781 32. 1000
P800 170M8611 1100 A, 1000 V 20 781 32. 1000
P900 170M8611 1100 A, 1000 V 20 781 32. 1000
P1M0 170M8611 1100 A, 1000 V 20 781 32. 1000
P1M2 170M8611 1100A, 1000V 20 781 32.1000
Table 8.33 Inverter module DC Link Fuses, 525-690V
*170M fuses from Bussmann shown use the -/80 visual indicator, -
TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size
and amperage may be substituted for external use.
Supplementary fuses
Size/Type Bussmann PN* Rating Alternative Fuses
2.5-4.0 A Fuse P450-P800, 380-500 V LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual
Element, Time Delay, 6A
P630-P1M2, 525-690 V LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual
Element, Time Delay, 10 A
4.0-6.3 A Fuse P450-P800, 380-500 V LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual
Element, Time Delay, 10 A
P630-P1M2, 525-690 V LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual
Element, Time Delay, 15 A
6.3 - 10 A Fuse P450-P800600HP-1200HP,
380-500 V
LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual
Element, Time Delay, 15 A
P630-P1M2, 525-690 V LPJ-20 SP or SPI 20 A, 600 V Any listed Class J Dual
Element, Time Delay, 20A
10 - 16 A Fuse P450-P800, 380-500 V LPJ-25 SP or SPI 25 A, 600 V Any listed Class J Dual
Element, Time Delay, 25 A
P630-P1M2, 525-690 V LPJ-20 SP or SPI 20 A, 600 V Any listed Class J Dual
Element, Time Delay, 20 A
Table 8.34 Manual Motor Controller Fuses
Frame size Bussmann PN* Rating
F8-F13 KTK-4 4 A, 600V
Table 8.35 SMPS Fuse
Size/Type Bussmann PN* LittelFuse Rating
P315-P800,
380-500 V
KLK-15 15A, 600V
P500-P1M2,
525-690 V
KLK-15 15A, 600V
Table 8.36 Fan Fuses
Frame size
Bussmann PN* Rating Alternative Fuses
F8-F13 LPJ-30 SP or SPI 30 A, 600 V Any listed Class J
Dual Element,
Time Delay, 30 A
Table 8.37 30 A Fuse Protected Terminal Fuse
Frame size Bussmann PN* Rating Alternative Fuses
F8-F13 LPJ-6 SP or SPI 6 A, 600 V Any listed Class J
Dual Element,
Time Delay, 6 A
Table 8.38 Control Transformer Fuse
Frame size
Bussmann PN* Rating
F8-F13 GMC-800MA 800mA, 250V
Table 8.39 NAMUR Fuse
Frame size Bussmann PN* Rating Alternative Fuses
F8-F13 LP-CC-6 6A, 600V Any listed Class
CC, 6A
Table 8.40 Safety Relay Coil Fuse with Pilz Relay
Electrical Installation FC 300 Design Guide
202 MG.33.BD.02 - VLT
®
is a registered Danfoss trademark
88
