Danfoss vlt FC 102 Programming Guide

3.9.6 8-5* Digital/Bus
Parameters for conguring the control word merging.
NOTICE
These parameters are active only when
parameter 8-01 Control Site is set to [0] Digital and control
word.
8-50 Coasting Select
Select the trigger for the coasting function.
Option: Function:
[0] Digital input A digital input triggers the coasting
function.
[1] Bus A serial communication port or the
eldbus triggers the coasting
function.
[2] Logic AND The eldbus/serial communication
port and a digital input trigger the
coasting function.
[3] * Logic OR The eldbus/serial communication
port or a digital input triggers the
coasting function.
8-52 DC Brake Select
Select control of the DC brake via the terminals (digital input)
and/or via the eldbus.
Option: Function:
NOTICE
When parameter 1-10 Motor
Construction is set to [1] PM
non-salient SPM, only selection
[0] Digital input is available.
[0] Digital input Activate a start command via a
digital input.
[1] Bus Activate a start command via the
serial communication port or
eldbus option.
[2] Logic AND Activate a start command via the
eldbus/serial communication port
and also via 1 of the digital inputs.
[3] Logic OR Activate a start command via the
eldbus/serial communication port
or via 1 of the digital inputs.
8-53 Start Select
Select the trigger for the start function.
Option: Function:
[0] Digital input A digital input triggers the start
function.
8-53 Start Select
Select the trigger for the start function.
Option: Function:
[1] Bus A serial communication port or the
eldbus triggers the start function.
[2] Logic AND The eldbus/serial communication
port and a digital input trigger the
start function.
[3] * Logic OR The eldbus/serial communication
port or a digital input triggers the
start function.
8-54 Reversing Select
Select control of the frequency converter reverse function via the
terminals (digital input) and/or via the eldbus.
Option: Function:
NOTICE
This parameter is active only
when parameter 8-01 Control
Site is set to [0] Digital and
control word.
[0] Digital input Activates reverse command via a
digital input.
[1] Bus Activates reverse command via the
serial communication port or
eldbus option.
[2] Logic AND Activates reverse command via the
eldbus/serial communication port
and via 1 of the digital inputs.
[3] Logic OR Activates reverse command via the
eldbus/serial communication port
or via 1 of the digital inputs.
8-55 Set-up Select
Select the trigger for the set-up selection.
Option: Function:
[0] Digital input A digital input triggers the set-up
selection.
[1] Bus A serial communication port or the
eldbus triggers the set-up
selection.
[2] Logic AND The eldbus/serial communication
port and a digital input trigger the
set-up selection.
[3] * Logic OR The eldbus/serial communication
port or a digital input triggers the
set-up selection.
Parameter Descriptions Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 123
