Danfoss vlt FC 102 Programming Guide

5.1.2 0-** Operation and Display
Paramet
er
number
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
0-0* Basic Settings
0-01 Language [0] English 1 set-up TRUE - Uint8
0-02 Motor Speed Unit [1] Hz 2 set-ups FALSE - Uint8
0-03 Regional Settings ExpressionLimit 2 set-ups FALSE - Uint8
0-04 Operating State at Power-up [0] Resume All set-ups TRUE - Uint8
0-05 Local Mode Unit [0] As Motor Speed Unit 2 set-ups FALSE - Uint8
0-1* Set-up Operations
0-10 Active Set-up [1] Set-up 1 1 set-up TRUE - Uint8
0-11 Programming Set-up [9] Active Set-up All set-ups TRUE - Uint8
0-12 This Set-up Linked to [0] Not linked All set-ups FALSE - Uint8
0-13 Readout: Linked Set-ups 0 N/A All set-ups FALSE 0 Uint16
0-14 Readout: Prog. Set-ups / Channel 0 N/A All set-ups TRUE 0 Int32
0-15 Readout: actual setup 0 N/A All set-ups FALSE 0 Uint8
0-2* LCP Display
0-20 Display Line 1.1 Small 1602 All set-ups TRUE - Uint16
0-21 Display Line 1.2 Small 1614 All set-ups TRUE - Uint16
0-22 Display Line 1.3 Small 1610 All set-ups TRUE - Uint16
0-23 Display Line 2 Large 1613 All set-ups TRUE - Uint16
0-24 Display Line 3 Large 1502 All set-ups TRUE - Uint16
0-25 My Personal Menu ExpressionLimit 1 set-up TRUE 0 Uint16
0-3* LCP Custom Readout
0-30 Custom Readout Unit [1] % All set-ups TRUE - Uint8
0-31 Custom Readout Min Value ExpressionLimit All set-ups TRUE -2 Int32
0-32 Custom Readout Max Value 100 CustomReadoutUnit All set-ups TRUE -2 Int32
0-37 Display Text 1 0 N/A 1 set-up TRUE 0 VisStr[25]
0-38 Display Text 2 0 N/A 1 set-up TRUE 0 VisStr[25]
0-39 Display Text 3 0 N/A 1 set-up TRUE 0 VisStr[25]
0-4* LCP Keypad
0-40 [Hand on] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-41 [O] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-42 [Auto on] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-43 [Reset] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-44 [O/Reset] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-45 [Drive Bypass] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-5* Copy/Save
0-50 LCP Copy [0] No copy All set-ups FALSE - Uint8
0-51 Set-up Copy [0] No copy All set-ups FALSE - Uint8
0-6* Password
0-60 Main Menu Password 100 N/A 1 set-up TRUE 0 Int16
0-61 Access to Main Menu w/o Password [0] Full access 1 set-up TRUE - Uint8
0-65 Personal Menu Password 200 N/A 1 set-up TRUE 0 Int16
0-66 Access to Personal Menu w/o Password [0] Full access 1 set-up TRUE - Uint8
0-67 Bus Access Password 0 N/A All set-ups TRUE 0 Uint16
0-7* Clock Settings
0-70 Date and Time ExpressionLimit All set-ups TRUE 0 TimeOfDay
0-71 Date Format ExpressionLimit 1 set-up TRUE - Uint8
0-72 Time Format ExpressionLimit 1 set-up TRUE - Uint8
0-73 Time Zone Oset 0 min 2 set-ups FALSE 70 Int16
0-74 DST/Summertime [0] O 1 set-up TRUE - Uint8
0-76 DST/Summertime Start ExpressionLimit 1 set-up TRUE 0 TimeOfDay
0-77 DST/Summertime End ExpressionLimit 1 set-up TRUE 0 TimeOfDay
0-79 Clock Fault ExpressionLimit 1 set-up TRUE - Uint8
0-81 Working Days ExpressionLimit 1 set-up TRUE - Uint8
0-82 Additional Working Days ExpressionLimit 1 set-up TRUE 0 TimeOfDay
0-83 Additional Non-Working Days ExpressionLimit 1 set-up TRUE 0 TimeOfDay
0-84 Time for Fieldbus 0 N/A All set-ups TRUE 0 Uint32
0-85 Summer Time Start for Fieldbus 0 N/A All set-ups TRUE 0 Uint32
0-86 Summer Time End for Fieldbus 0 N/A All set-ups TRUE 0 Uint32
0-89 Date and Time Readout 0 N/A All set-ups TRUE 0 VisStr[25]
0-9* Varia
0-95 Warning LED blinking [0] Constant On 1 set-up TRUE - Uint8
Parameter Lists
VLT
®
HVAC Drive FC 102
292 Danfoss A/S © 10/2019 All rights reserved. M0010001
55
