2.1.7 Main Menu Mode
Press [Main Menu] to select the Main Menu mode. The
below readout appears on the display.
The middle and bottom sections on the display show a list
of parameter groups which can be selected by toggling
the [▲] and [▼] keys.
e30bp066.14
0-** Operation/Display
1-** Load/Motor
2-** Brakes
1107 RPM 3.84 A
Main Menu
1(1)
3-** References/Ramps
Illustration 2.27 Main Menu Mode
Each parameter has a name and number which remain the
same regardless of the programming mode. In the main
menu mode, the parameters are divided into groups. The
1
st
digit of the parameter number (from the left) indicates
the parameter group number.
All parameters can be changed in the Main Menu.
However, depending on the conguration
(parameter 1-00 Conguration Mode), some parameters can
be hidden.
2.1.8 Parameter Selection
In the main menu mode, the parameters are divided into
groups. Press the navigation keys to select parameter
group.
The following parameter groups are accessible:
Group no. Parameter group
0 Operation/Display
1 Load/Motor
2 Brakes
3 References/Ramps
4 Limits/Warnings
5 Digital In/Out
6 Analog In/Out
8 Comm. and Options
9 PROFIBUS
10 CAN Fieldbus
11 LonWorks
12 Ethernet IP/Modbus TCP/PROFINET
13 Smart Logic
14 Special Functions
15 Drive Information
16 Data Readouts
18 Data Readouts 2
20 Drive Closed Loop
21 Ext. Closed Loop
22 Application Functions
Group no. Parameter group
23 Time-based Functions
25 Cascade Controller
26 Analog I/O Option MCB 109
Table 2.6 Parameter Selection
After selecting a parameter group, press the navigation
keys to select a parameter.
The middle section on the display shows the parameter
number and name, and the selected parameter value.
130BP067.10
740RPM
0 -01 Language
[0] English
10.64A 1 [1]
0-0
*
Basic Settings
Illustration 2.28 Parameter Selection
2.1.9 Changing Data
Press [OK] to change the selected parameter. The
procedure for changing data depends on whether the
selected parameter represents a numerical data value or a
text value.
2.1.10 Changing a Text Value
If the selected parameter is a text value, change the text
value with the [
▲
] [
▼
] keys.
Place the cursor on the value that should be saved and
press [OK].
130BP068.10
740RPM
0 -01 Language
[0] English
10.64 A 1 [1]
0-0
*
Basic Settings
Illustration 2.29 Changing a Text Value
How to Programme Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 23
2 2

Danfoss vlt FC 102 Specifications

General

Category	DC Drives
Model	Danfoss VLT FC 102
Output voltage range	0 to rated motor voltage
Power range	0.37 kW to 200 kW
Communication interfaces	RS-485
Protection features	Overvoltage, undervoltage, overcurrent, short circuit, earth fault, overtemperature, motor thermal protection
Cooling method	Air-cooled
Enclosure rating	IP20, IP21, IP55 (depending on model)
Approvals	CE, UL, cUL
