26-62 Terminal X42/11 Max. Scale
See Illustration 3.31.
Range: Function:
100 %* [0 - 200 %] Scale the maximum output of the
selected analog signal at terminal
X42/9. Set the value to the
maximum value of the voltage
signal output. Scale the output to
give a voltage lower than 10 V at
full scale; or 10 V at an output
below 100% of the maximum signal
value. For example, if 10 V is the
required output current at a value
between 0–100% of the full-scale
output, program the percentage
value in the parameter, that is,
50%=10 V. If a voltage 0–10 V is
required at maximum output,
calculate the percentage as follows:
10V
desiredmaximumvoltage
x100 %
that is
5V :
10V
5V
x100 % = 200 %
26-63 Terminal X42/11 Bus Control
Range: Function:
0 %* [0 - 100 %] Holds the level of terminal X42/11 if
controlled by bus.
26-64 Terminal X42/11 Timeout Preset
Range: Function:
0 %* [0 - 100 %] Holds the preset level of terminal
X42/11.
If a eldbus and a timeout function
are selected, the output presets to
this level.
3.25 Parameters: 30-** Special Features
30-22 Locked Rotor Detection
Available for PM motors only, in VVC
+
open-loop mode.
Option: Function:
[0] O
[1] On Protects the motor from the locked
rotor condition. The control
algorithm detects a possible locked
rotor condition in motor and trips
the frequency converter to protect
the motor.
30-23 Locked Rotor Detection Time [s]
Available for PM motors only, in ux sensorless-mode and VVC
+
open-loop mode.
Range: Function:
Size
related*
[0.05 - 1 s] Time period for detecting the
locked-rotor condition. A low
parameter value leads to faster
detection.
Parameters for conguring the wireless LCP 103.
30-90 SSID
Range: Function:
Size
related*
[1 - 32 ] Enter the wireless network name
(SSID). The default value is:
Danfoss_<Serial number of the
frequency converter>. The serial
number is in
parameter 15-51 Frequency Converter
Serial Number.
30-91 Channel
Range: Function:
5* [1 - 11 ] Enter the wireless channel number.
The default channel number is 5.
Change the channel number, if
there is an interference from other
wireless networks. Recommended
channels:
USA territory: 1, 6, 11.
Europe: 1, 7, 13.
30-92 Password
Range: Function:
Size
related*
[8 - 48 ] Enter the wireless network
password. Password length: 8–48
characters.
30-93 Security type
Select the wireless network security type.
Option: Function:
[2] * WPA_WPA2
30-94 IP address
Range: Function:
Size
related*
[0 -
4294967295 ]
Enter the IP address to connect to.
30-95 Submask
Range: Function:
Size
related*
[0 -
4294967295 ]
Enter the subnet mask.
Parameter Descriptions
VLT
®
HVAC Drive FC 102
256 Danfoss A/S © 10/2019 All rights reserved. M0010001
