Danfoss vlt FC 102 Programming Guide

5.1.22 24-** Application Functions 2
Parameter
number
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
24-0* Fire Mode
24-00 Fire Mode Function [0] Disabled 2 set-ups TRUE - Uint8
24-01 Fire Mode Conguration [0] Open Loop All set-ups TRUE - Uint8
24-02 Fire Mode Unit ExpressionLimit All set-ups TRUE - Uint8
24-03 Fire Mode Min Reference ExpressionLimit All set-ups TRUE -3 Int32
24-04 Fire Mode Max Reference ExpressionLimit All set-ups TRUE -3 Int32
24-05 Fire Mode Preset Reference 0 % All set-ups TRUE -2 Int16
24-06 Fire Mode Reference Source [0] No function All set-ups TRUE - Uint8
24-07 Fire Mode Feedback Source [0] No function All set-ups TRUE - Uint8
24-09 Fire Mode Alarm Handling [1] Trip, Critical Alarms 2 set-ups FALSE - Uint8
24-1* Drive Bypass
24-10 Drive Bypass Function [0] Disabled 2 set-ups TRUE - Uint8
24-11 Drive Bypass Delay Time 0 s 2 set-ups TRUE 0 Uint16
24-9* Multi-Motor Funct.
24-90 Missing Motor Function [0] O All set-ups TRUE - Uint8
24-91 Missing Motor Coecient 1 0 N/A All set-ups TRUE -4 Int32
24-92 Missing Motor Coecient 2 0 N/A All set-ups TRUE -4 Int32
24-93 Missing Motor Coecient 3 0 N/A All set-ups TRUE -4 Int32
24-94 Missing Motor Coecient 4 0 N/A All set-ups TRUE -3 Int32
24-95 Locked Rotor Function [0] O All set-ups TRUE - Uint8
24-96 Locked Rotor Coecient 1 0 N/A All set-ups TRUE -4 Int32
24-97 Locked Rotor Coecient 2 0 N/A All set-ups TRUE -4 Int32
24-98 Locked Rotor Coecient 3 0 N/A All set-ups TRUE -4 Int32
24-99 Locked Rotor Coecient 4 0 N/A All set-ups TRUE -3 Int32
Parameter Lists
VLT
®
HVAC Drive FC 102
310 Danfoss A/S © 10/2019 All rights reserved. M0010001
55
