36-61 Terminal X49/11 Digital Output
Select the function of Terminal X49/11 as an analog voltage
output.
Option: Function:
[152] ATEX ETR freq.
alarm
[153] ATEX ETR cur.
warning
[154] ATEX ETR freq.
warning
[160] No alarm
[161] Running
reverse
[163] Pressure
Sensor
[165] Local ref
active
[166] Remote ref
active
[167] Start
command
activ
[168] Hand / O
[169] Auto mode
[180] Clock Fault
[181] Prev.
Maintenance
[188] AHF Capacitor
Connect
[189] External Fan
Control
[190] No-Flow
[191] Dry Pump
[192] End Of Curve
[193] Sleep Mode
[194] Broken Belt
[195] Bypass Valve
Control
[196] Fire Mode
[197] Fire Mode was
Act.
[198] Drive Bypass
[200] Full capacity
[201] Pump 1
running
[202] Pump 2
running
[203] Pump 3
running
[236] Ext. CL 1 on
Ref
[237] Ext. CL 2 on
Ref
[238] Ext. CL 3 on
Ref
36-61 Terminal X49/11 Digital Output
Select the function of Terminal X49/11 as an analog voltage
output.
Option: Function:
[240] RS Flipop 0
[241] RS Flipop 1
[242] RS Flipop 2
[243] RS Flipop 3
[244] RS Flipop 4
[245] RS Flipop 5
[246] RS Flipop 6
[247] RS Flipop 7
36-62 Terminal X49/11 Min. Scale
Range: Function:
0 %* [0 - 200 %] Match the minimum output of
terminal X49/11 with a required
value. For more information, see
parameter 36-42 Terminal X49/7 Min.
Scale.
36-63 Terminal X49/11 Max. Scale
Range: Function:
100 %* [0 - 200 %] Scale the maximum output of
terminal X49/11. For more
information, see
parameter 36-43 Terminal X49/7 Max.
Scale.
36-64 Terminal X49/11 Bus Control
Range: Function:
0 %* [0 - 100 %] This parameter contains the output
level of terminal X49/11 if the
terminal is controlled by a eldbus.
36-65 Terminal X49/11 Timeout Preset
Range: Function:
0 %* [0 - 100 %] The frequency converter sends the
value of this parameter to the
output terminal when the terminal
is controlled by a eldbus and a
timeout is detected.
3.30 Parameters: 40-** Special Settings
40-40 Alarm Log: Ext. Reference
Range: Function:
0 %* [-200 -
200 %]
40-41 Alarm Log: Frequency
Range: Function:
0 Hz* [0 - 6500 Hz]
Parameter Descriptions Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 271
3 3
