0-81 Working Days
Array [7]
Array with 7 elements [0]–[6] shown below the parameter
number in the display. Press [OK] and step between elements
with [
▲
] and [
▼
].
Option: Function:
Set for each weekday if it is a
working day or a non-working day.
First element of the array is
Monday. The working days are used
for timed actions.
[0] No
[1] Yes
0-82 Additional Working Days
Array [5]
Array with 5 elements [0]–[4] shown below the parameter
number in the display. Press [OK] and step between elements
with [
▲
] and [
▼
].
Range: Function:
Size
related*
[ 0 - 0 ] Denes dates for additional working
days that would normally be non-
working days according to
parameter 0-81 Working Days.
0-83 Additional Non-Working Days
Array [15]
Array with 15 elements [0]–[14] shown below the parameter
number in the display. Press [OK] and step between elements
with [
▲
] and [
▼
].
Range: Function:
Size
related*
[ 0 - 0 ] Denes dates for additional working
days that would normally be non-
working days according to
parameter 0-81 Working Days.
0-84 Time for Fieldbus
Range: Function:
0* [0 -
4294967295 ]
Shows the time for eldbus.
0-85 Summer Time Start for Fieldbus
Range: Function:
0* [0 -
4294967295 ]
Shows the summer time start for
eldbus.
0-86 Summer Time End for Fieldbus
Range: Function:
0* [0 -
4294967295 ]
Shows the summer time end for
eldbus.
0-89 Date and Time Readout
Range: Function:
0* [0 - 25 ] Shows the current date and time.
The date and time is updated
continuously.
The clock does not begin counting
until a setting dierent from default
has been made in
parameter 0-70 Date and Time.
0-95 Warning LED blinking
Option: Function:
[0] * Constant On
[1] Blinking
3.3 Parameters: 1-** Load and Motor
3.3.1 1-0* General Settings
Dene whether the frequency converter operates in open
loop or closed loop.
1-00 Conguration Mode
Option: Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
NOTICE
When set to [3] Closed Loop,
the commands reversing and
start reversing do not reverse
the motor direction.
[0] Open Loop Motor speed is determined by
applying a speed reference or by
setting the speed when in hand-on
mode.
Open loop is also used if the
frequency converter is part of a
closed-loop control system based
on an external PID controller
providing a speed reference signal
as output.
[3] Closed Loop Motor speed is determined by a
reference from the built-in PID
controller varying the motor speed
as in a closed-loop control process
(for example constant pressure or
ow). Congure the PID controller
in parameter group 20-** Feedback
or via the Function Set-ups accessed
by pressing [Quick Menu].
Parameter Descriptions
VLT
®
HVAC Drive FC 102
48 Danfoss A/S © 10/2019 All rights reserved. M0010001
