Danfoss vlt FC 102 Programming Guide

13-02 Stop Event
Option: Function:
Select the boolean (true or false)
input to deactivate smart logic
control.
[0] False Enters the xed value of false in the
logic rule.
[1] True Enters the xed value of true in the
logic rule.
[2] Running See parameter group 5-3* Digital
Outputs for further description.
[3] In range See parameter group 5-3* Digital
Outputs for further description.
[4] On reference See parameter group 5-3* Digital
Outputs for further description.
[5] Torque limit See parameter group 5-3* Digital
Outputs for further description.
[6] Current Limit See parameter group 5-3* Digital
Outputs for further description.
[7] Out of current
range
See parameter group 5-3* Digital
Outputs for further description.
[8] Below I low See parameter group 5-3* Digital
Outputs for further description.
[9] Above I high See parameter group 5-3* Digital
Outputs for further description.
[10] Out of speed
range
[11] Below speed
low
See parameter group 5-3* Digital
Outputs for further description.
[12] Above speed
high
See parameter group 5-3* Digital
Outputs for further description.
[13] Out of feedb.
range
See parameter group 5-3* Digital
Outputs for further description.
[14] Below feedb.
low
See parameter group 5-3* Digital
Outputs for further description.
[15] Above feedb.
high
See parameter group 5-3* Digital
Outputs for further description.
[16] Thermal
warning
See parameter group 5-3* Digital
Outputs for further description.
[17] Mains out of
range
See parameter group 5-3* Digital
Outputs for further description.
[18] Reversing See parameter group 5-3* Digital
Outputs for further description.
[19] Warning See parameter group 5-3* Digital
Outputs for further description.
[20] Alarm (trip) See parameter group 5-3* Digital
Outputs for further description.
13-02 Stop Event
Option: Function:
[21] Alarm (trip
lock)
See parameter group 5-3* Digital
Outputs for further description.
[22] Comparator 0 Use the result of comparator 0 in
the logic rule.
[23] Comparator 1 Use the result of comparator 1 in
the logic rule.
[24] Comparator 2 Use the result of comparator 2 in
the logic rule.
[25] Comparator 3 Use the result of comparator 3 in
the logic rule.
[26] Logic rule 0 Use the result of logic rule 0 in the
logic rule.
[27] Logic rule 1 Use the result of logic rule 1 in the
logic rule.
[28] Logic rule 2 Use the result of logic rule 2 in the
logic rule.
[29] Logic rule 3 Use the result of logic rule 3 in the
logic rule.
[30] SL Time-out 0 Use the result of timer 0 in the
logic rule.
[31] SL Time-out 1 Use the result of timer 1 in the
logic rule.
[32] SL Time-out 2 Use the result of timer 2 in the
logic rule.
[33] Digital input
DI18
Use the value of DI18 in the logic
rule (High = true).
[34] Digital input
DI19
Use the value of DI19 in the logic
rule (High = true).
[35] Digital input
DI27
Use the value of DI27 in the logic
rule (High = true).
[36] Digital input
DI29
Use the value of DI29 in the logic
rule (High = true).
[37] Digital input
DI32
Use the value of DI32 in the logic
rule (High = true).
[38] Digital input
DI33
Use the value of DI33 in the logic
rule (High = true).
[39] Start
command
This event is true if the frequency
converter is started (either via
digital input, eldbus, or other).
[40] Drive stopped This event is true if the frequency
converter is stopped or coasted
(either via digital input, eldbus, or
other).
[41] Reset Trip This event is true if the frequency
converter is tripped (but not trip-
locked) and [Reset] is pressed.
Parameter Descriptions
VLT
®
HVAC Drive FC 102
128 Danfoss A/S © 10/2019 All rights reserved. M0010001
33
