Danfoss vlt FC 102 Programming Guide

13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[24] Comparator 2 Use the result of comparator 2 in
the logic rule.
[25] Comparator 3 Use the result of comparator 3 in
the logic rule.
[26] Logic rule 0 Use the result of logic rule 0 in the
logic rule.
[27] Logic rule 1 Use the result of logic rule 1 in the
logic rule.
[28] Logic rule 2 Use the result of logic rule 2 in the
logic rule.
[29] Logic rule 3 Use the result of logic rule 3 in the
logic rule.
[30] SL Time-out 0 Use the result of timer 0 in the
logic rule.
[31] SL Time-out 1 Use the result of timer 1 in the
logic rule.
[32] SL Time-out 2 Use the result of timer 2 in the
logic rule.
[33] Digital input
DI18
Use the value of DI18 in the logic
rule (High = true).
[34] Digital input
DI19
Use the value of DI19 in the logic
rule (High = true).
[35] Digital input
DI27
Use the value of DI27 in the logic
rule (High = true).
[36] Digital input
DI29
Use the value of DI29 in the logic
rule (High = true).
[37] Digital input
DI32
Use the value of DI32 in the logic
rule (High = true).
[38] Digital input
DI33
Use the value of DI33 in the logic
rule (High = true).
[39] Start
command
This logic rule is true if the
frequency converter is started
either via digital input, eldbus, or
other.
[40] Drive stopped This logic rule is true if the
frequency converter is stopped or
coasted either via digital input,
eldbus, or other.
[41] Reset Trip This logic rule is true if the
frequency converter is tripped (but
not trip-locked) and [Reset] is
pressed.
[42] Auto Reset
Trip
This logic rule is true if the
frequency converter is tripped (but
not trip-locked) and an automatic
reset is issued.
13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[43] OK Key This logic rule is true if [OK] is
pressed.
[44] Reset Key This logic rule is true if [Reset] is
pressed.
[45] Left Key
This logic rule is true if [◄] is
pressed.
[46] Right Key
This logic rule is true if [►] is
pressed.
[47] Up Key
This logic rule is true if [
▲
] is
pressed.
[48] Down Key
This logic rule is true if [
▼
] is
pressed.
[50] Comparator 4 Use the result of comparator 4 in
the logic rule.
[51] Comparator 5 Use the result of comparator 5 in
the logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the
logic rule.
[61] Logic rule 5 Use the result of logic rule 5 in the
logic rule.
[70] SL Time-out 3 Use the result of timer 3 in the
logic rule.
[71] SL Time-out 4 Use the result of timer 4 in the
logic rule.
[72] SL Time-out 5 Use the result of timer 5 in the
logic rule.
[73] SL Time-out 6 Use the result of timer 6 in the
logic rule.
[74] SL Time-out 7 Use the result of timer 7 in the
logic rule.
[76] Digital Input
x30 2
[77] Digital Input
x30 3
[78] Digital Input
x30 4
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
[90] ECB Drive
Mode
[91] ECB Bypass
Mode
[92] ECB Test Mode
[93] RS Flipop 6
[94] RS Flipop 0
Parameter Descriptions Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 137
3 3
