Danfoss vlt FC 102 Programming Guide

16-77 Analog Out X30/8 [mA]
Range: Function:
0* [0 - 30 ] View the actual value at input
X30/8 in mA.
3.16.6 16-8* Fieldbus & FC Port
Parameters for reporting the bus references and control
words.
16-80 Fieldbus CTW 1
Range: Function:
0* [0 - 65535 ] View the 2-byte control word (CTW)
received from the eldbus master.
Interpretation of the control word
depends on the eldbus option
installed and the control word
prole selected in
parameter 8-10 Control Prole.
For more information, refer to the
relevant eldbus manual.
16-82 Fieldbus REF 1
Range: Function:
0* [-200 - 200 ] View the 2-byte word sent with the
control word from the eldbus
master to set the reference value.
For more information, refer to the
relevant eldbus manual.
16-84 Comm. Option STW
Range: Function:
0* [0 - 65535 ] Show the status word of the
extended eldbus communication
option.
For more information, refer to the
relevant eldbus manual.
16-85 FC Port CTW 1
Range: Function:
0* [0 - 65535 ] View the 2-byte control word (CTW)
received from the eldbus master.
Interpretation of the control word
depends on the eldbus option
installed and the control word
prole selected in
parameter 8-10 Control Prole.
16-86 FC Port REF 1
Range: Function:
0* [-200 - 200 ] View the 2-byte status word (STW)
sent to the eldbus master.
Interpretation of the status word
depends on the eldbus option
installed and the control word
16-86 FC Port REF 1
Range: Function:
prole selected in
parameter 8-10 Control Prole.
3.16.7 16-9* Diagnosis Readouts
NOTICE
When using MCT 10 Set-up Software, the readout
parameters can only be read online, that is as the actual
status. This means that the status is not stored in the
MCT 10 Set-up Software le.
16-90 Alarm Word
Range: Function:
0* [0 -
4294967295 ]
Show the alarm word sent via the
serial communication port in hex
code.
16-91 Alarm Word 2
Range: Function:
0* [0 -
4294967295 ]
View the alarm word 2 sent via the
serial communication port in hex
code.
16-92 Warning Word
Range: Function:
0* [0 -
4294967295 ]
Show the warning word sent via
the serial communication port in
hex code.
16-93 Warning Word 2
Range: Function:
0* [0 -
4294967295 ]
View the warning word 2 sent via
the serial communication port in
hex code.
16-94 Ext. Status Word
Range: Function:
0* [0 -
4294967295 ]
Returns the extended status word
sent via the serial communication
port in hex code.
16-95 Ext. Status Word 2
Range: Function:
0* [0 -
4294967295 ]
Returns the extended warning word
2 sent via the serial communication
port in hex code.
Parameter Descriptions Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 169
3 3
