Danfoss vlt FC 102 Programming Guide

0-24 Display Line 3 Large
Option: Function:
[1666] Digital Output
[bin]
[1667] Pulse Input
#29 [Hz]
[1668] Pulse Input
#33 [Hz]
[1669] Pulse Output
#27 [Hz]
[1670] Pulse Output
#29 [Hz]
[1671] Relay Output
[bin]
[1672] Counter A
[1673] Counter B
[1675] Analog In
X30/11
[1676] Analog In
X30/12
[1677] Analog Out
X30/8 [mA]
[1678] Analog Out
X45/1 [mA]
[1679] Analog Out
X45/3 [mA]
[1680] Fieldbus CTW
1
[1682] Fieldbus REF 1
[1684] Comm. Option
STW
[1685] FC Port CTW 1
[1686] FC Port REF 1
[1687] Bus Readout
Alarm/Warning
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word
2
[1694] Ext. Status
Word
[1695] Ext. Status
Word 2
[1696] Maintenance
Word
[1697] Alarm Word 3
[1698] Warning Word
3
[1830] Analog Input
X42/1
[1831] Analog Input
X42/3
[1832] Analog Input
X42/5
0-24 Display Line 3 Large
Option: Function:
[1833] Analog Out
X42/7 [V]
[1834] Analog Out
X42/9 [V]
[1835] Analog Out
X42/11 [V]
[1836] Analog Input
X48/2 [mA]
[1837] Temp. Input
X48/4
[1838] Temp. Input
X48/7
[1839] Temp. Input
X48/10
[1840] Analog Input
X49/1
[1841] Analog Input
X49/3
[1842] Analog Input
X49/5
[1843] Analog Out
X49/7
[1844] Analog Out
X49/9
[1845] Analog Out
X49/11
[1846] X49 Digital
Output [bin]
[1850] Sensorless
Readout [unit]
[1857] Air Pressure to
Flow Air Flow
[1860] Digital Input 2
[1870] Mains Voltage
[1871] Mains
Frequency
[1872] Mains
Imbalance
[1875] Rectier DC
Volt.
[2117] Ext. 1
Reference
[Unit]
[2118] Ext. 1
Feedback
[Unit]
[2119] Ext. 1 Output
[%]
[2137] Ext. 2
Reference
[Unit]
[2138] Ext. 2
Feedback
[Unit]
Parameter Descriptions
VLT
®
HVAC Drive FC 102
40 Danfoss A/S © 10/2019 All rights reserved. M0010001
