380–480 V
Enclosure
type
Power [kW] Recommended
fuse size
Recommended
Max. fuse size
Recommended circuit
breaker (Moeller)
Max. trip level [A]
A2 1.1–4.0 gG-10 (1.1–3)
gG-16 (4)
gG-25 PKZM0-25 25
A3 5.5–7.5 gG-16 gG-32 PKZM0-25 25
B3 11–18 gG-40 gG-63 PKZM4-50 50
B4 22–37 gG-50 (22)
gG-63 (30)
gG-80 (37)
gG-125 NZMB1-A100 100
C3 45–55 gG-100 (45)
gG-160 (55)
gG-150 (45)
gG-160 (55)
NZMB2-A200 150
C4 75–90 aR-200 (75)
aR-250 (90)
aR-250 NZMB2-A250 250
A4 1.1–4 gG-10 (1.1–3)
gG-16 (4)
gG-32 PKZM0-25 25
A5 1.1–7.5 gG-10 (1.1–3)
gG-16 (4–7.5)
gG-32 PKZM0-25 25
B1 11–18.5 gG-40 gG-80 PKZM4-63 63
B2 22–30 gG-50 (22)
gG-63 (30)
gG-100 NZMB1-A100 100
C1 37–55 gG-80 (37)
gG-100 (45)
gG-160 (55)
gG-160 NZMB2-A200 160
C2 75–90 aR-200 (75)
aR-250 (90)
aR-250 NZMB2-A250 250
Table 8.13 380–480 V, Enclosure Types A, B and C
Specifications
VLT
®
HVAC Drive Instruction Manual
70 MG11AJ22 - Rev. 2013-09-13
