Danfoss vlt FC 102 Instruction Manual

525–600 V
Enclosure
type
Power [kW] Recommended
fuse size
Recommended
Max. fuse size
Recommended circuit
breaker (Moeller)
Max. trip level [A]
A3 5.5–7.5 gG-10 (5.5)
gG-16 (7.5)
gG-32 PKZM0-25 25
B3 11–18 gG-25 (11)
gG-32 (15-18)
gG-63 PKZM4-50 50
B4 22–37 gG-40 (22)
gG-50 (30)
gG-63 (37)
gG-125 NZMB1-A100 100
C3 45–55 gG-63 (45)
gG-100 (55)
gG-150 NZMB2-A200 150
C4 75–90 aR-160 (75)
aR-200 (90)
aR-250 NZMB2-A250 250
A5 1.1–7.5 gG-10 (1.1–5.5)
gG-16 (7.5)
gG-32 PKZM0-25 25
B1 11–18 gG-25 (11)
gG-32 (15)
gG-40 (18.5)
gG-80 PKZM4-63 63
B2 22–30 gG-50 (22)
gG-63 (30)
gG-100 NZMB1-A100 100
C1 37–55 gG-63 (37)
gG-100 (45)
aR-160 (55)
gG-160 (37–45)
aR-250 (55)
NZMB2-A200 160
C2 75–90 aR-200 (75–90) aR-250 NZMB2-A250 250
Table 8.14 525–600 V, Enclosure Types A, B and C
525–690 V
Enclosure
type
Power [kW] Recommended
fuse size
Recommended
Max. fuse size
Recommended circuit
breaker (Moeller)
Max. trip level [A]
A3 1.1
1.5
2.2
3
4
5.5
7.5
gG-6
gG-6
gG-6
gG-10
gG-10
gG-16
gG-16
gG-25
gG-25
gG-25
gG-25
gG-25
gG-25
gG-25
- -
B2/B4 11
15
18
22
gG-25 (11)
gG-32 (15)
gG-32 (18)
gG-40 (22)
gG-63 - -
B4/C2 30 gG-63 (30) gG-80 (30)
C2/C3 37
45
gG-63 (37)
gG-80 (45)
gG-100 (37)
gG-125 (45)
- -
C2 55
75
gG-100 (55)
gG-125 (75)
gG-160 (55–75) - -
Table 8.15 525–690 V, Enclosure Types A, B and C
