FC 103 N450 N500 N560
Continuous (at 575/690 V) [A] 450 500 570
Intermittent (60 s overload) (at 575/690 V) [A] 495 550 627
Continuous kVA (at 525 V) [kVA] 427 476 542
Continuous kVA (at 575 V) [kVA] 448 498 568
Continuous kVA (at 690 V) [kVA] 538 598 681
Maximum input current
Continuous (at 525 V) [A] 453 504 574
Continuous (at 575/690 V) [A] 434 482 549
Maximum number and size of cables per phase (E1h)
- Mains and motor without brake [mm
2
(AWG)]
5x240 (5x500 mcm) 5x240 (5x500 mcm) 5x240 (5x500 mcm)
- Mains and motor with brake [mm
2
(AWG)]
4x240 (4x500 mcm) 4x240 (4x500 mcm) 4x240 (4x500 mcm)
- Brake or regen [mm
2
(AWG)]
2x185 (2x350 mcm) 2x185 (2x350 mcm) 2x185 (2x350 mcm)
Maximum number and size of cables per phase (E3h)
- Mains and motor [mm
2
(AWG)]
6x240 (6x500 mcm) 6x240 (6x500 mcm) 6x240 (6x500 mcm)
- Brake [mm
2
(AWG)]
2x185 (2x350 mcm) 2x185 (2x350 mcm) 2x185 (2x350 mcm)
- Load share or regen [mm
2
(AWG)]
4x185 (4x350 mcm) 4x185 (4x350 mcm) 4x185 (4x350 mcm)
Maximum external mains fuses [A]
(1)
800 800 800
Estimated power loss at 600 V [W]
(2) (3)
5758 6516 7629
Estimated power loss at 690 V [W]
(2) (3)
5935 6711 7846
Efficiency
(3)
0.98 0.98 0.98
Output frequency [Hz] 0–590 0–590 0–590
Heat sink overtemperature trip [°C (°F)] 110 (230) 110 (230) 110 (230)
Control card overtemperature trip [°C (°F)] 80 (176) 80 (176) 80 (176)
Power card overtemperature trip [°C (°F)] 85 (185) 85 (185) 85 (185)
Fan power card overtemperature trip [°C (°F)] 85 (185) 85 (185) 85 (185)
Active in-rush card overtemperature trip [°C (°F)] 85 (185) 85 (185) 85 (185)
1
For fuse ratings, see 9.7 Fuses.
2
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These values are based on a typical motor
efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the drive. Applies for dimensioning of drive cooling. If the switching frequency is higher than the default
setting, the power losses can increase. LCP and typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to www.danfoss.com/
vltenergyefficiency. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each add only 4 W.
3
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Efficiency measured at nominal current. For energy efficiency class, see 9.4 Ambient
Conditions. For part load losses, see www.danfoss.com/vltenergyefficiency.
