3 Product Overview
3.1 Power Ratings, Weights, and Dimensions for E1h–E4h Enclosures
Table 2: Power Ratings, Weights, and Dimensions for E1h–E4h Enclosures (Standard Configurations)
Enclosure size E1h E2h E3h E4h
Rated power at 380–480 V [kW
(hp)]
355–450 (500–600) 500–560 (650–750) 355–450 (500–600) 500–560 (650–750)
Rated power at 525–690 V [kW
(hp)]
450–6300 (450–650) 710–800 (750–950) 450–630 (450–650) 710–800 (750–950)
Enclosure protection rating
(1)
IP21/Type 1 IP54/
Type 12
IP21/Type 1 IP54/
Type 12
IP20/Chassis IP20/Chassis
Unit dimensions
Height [mm (in)] 2043 (80.4) 2043 (80.4) 1578 (62.1) 1578 (62.1)
Width [mm (in)] 602 (23.7) 698 (27.5) 506 (19.9) 604 (23.89)
Depth [mm (in)] 513 (20.2) 513 (20.2) 482 (19.0) 482 (19.0)
Weight [kg (lb)] 295 (650) 318 (700) 272 (600) 295 (650)
Shipping dimensions
Height [mm (in)] 2191 (86.3) 2191 (86.3) 1759 (69.3) 1759 (69.3)
Width [mm (in)] 768 (30.2) 768 (30.2) 746 (29.4) 746 (29.4)
Depth [mm (in)] 870 (34.3) 870 (34.3) 794 (31.3) 794 (31.3)
Weight [kg (lb)] – – – –
1
Type 1 and Type 12 are UL designations.
Product Overview
Operating Guide | VLT® Refrigeration Drive FC 103
AQ275652766279en-000101 / 130R0707
12 | Danfoss A/S © 2020.01
