5.9 E3h Terminal Dimensions
e30bf660.10
336 (13.2)
425 (16.7)
376 (14.8) 465 (18.3)
256 (10.1)
33 (1.3)
6X 148 (5.8)
90 (3.5)
50 (2.0)
0 (0.0)
0 (0.0)
64 (2.5)
35 (1.4)
91 (3.6)
118 (4.6)
194 (7.6)
174 (6.9) 201 (7.9)
284 (11.2)
340 (13.4)
314 (12.3)
367 (14.4)
444 (17.5)
423 (16.7) 450 (17.7)
2
3
4
1
1 Mains terminals
3 Motor terminals
2 Brake or regen terminals
4 Ground terminals, M8 and M10 nuts
Illustration 25: E3h Terminal Dimensions (Front View)
Electrical Installation
Operating Guide | VLT® Refrigeration Drive FC 103
AQ275652766279en-000101 / 130R0707
50 | Danfoss A/S © 2020.01
