FC 103 N500 N560
- Brake or regen [mm
2
(AWG)]
2x185 (2x350 mcm) 2x185 (2x350 mcm)
Maximum number and size of cables per phase (E4h)
- Mains and motor [mm
2
(AWG)]
6x240 (6x500 mcm) 6x240 (6x500 mcm)
- Brake [mm
2
(AWG)]
2x185 (2x350 mcm) 2x185 (2x350 mcm)
- Load share or regen [mm
2
(AWG)]
4x185 (4x350 mcm) 4x185 (4x350 mcm)
Maximum external mains fuses [A]
(1)
1200 1200
Estimated power loss at 400 V [W]
(2) (3)
9473 11102
Estimated power loss at 460 V [W]
(2) (3)
7809 9236
Efficiency
(3)
0.98 0.98
Output frequency [Hz] 0–590 0–590
Heat sink overtemperature trip [°C (°F)] 110 (230) 100 (212)
Control card overtemperature trip [°C (°F)] 80 (176) 80 (176)
Power card overtemperature trip [°C (°F)] 85 (185) 85 (185)
Fan power card overtemperature trip [°C (°F)] 85 (185) 85 (185)
Active in-rush card overtemperature trip [°C (°F)] 85 (185) 85 (185)
1
For fuse ratings, see 9.7 Fuses.
2
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These values are based on a typical motor
efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the drive. Applies for dimensioning of drive cooling. If the switching frequency is higher than the default
setting, the power losses can increase. LCP and typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to www.danfoss.com/
vltenergyefficiency. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each add only 4 W.
3
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Efficiency measured at nominal current. For energy efficiency class, see 9.4 Ambient
Conditions. For part load losses, see www.danfoss.com/vltenergyefficiency.
9.1.2 Electrical Data, 525–690 V AC
Table 44: Electrical Data, Mains Supply 3x525–690 V AC
FC 103 N450 N500 N560
High/normal overload
High overload=150% or 160% torque for a duration of 60 s.
Normal overload=110% torque for a duration of 60 s.
NO NO NO
Typical shaft output at 525 V [kW] 355 400 450
Typical shaft output at 575 V [hp] 450 500 600
Typical shaft output at 690 V [kW] 450 500 560
Enclosure size E1h/E3h E1h/E3h E1h/E3h
Output current (3-phase)
Continuous (at 525 V) [A] 470 523 596
Intermittent (60 s overload) (at 525 V) [A] 517 575 656
Specifications
Operating Guide | VLT® Refrigeration Drive FC 103
AQ275652766279en-000101 / 130R0707| 129
Danfoss A/S © 2020.01
