Danfoss VLT FC 103 Operating Guide

5.8 E2h Terminal Dimensions
e30bf689.10
721 (28.4)
6X
613 (24.1)
1
515 (20.3)
485 (19.1)
0 (0.0)
200 (7.9)
185 (7.3)
0 (0.0)
101 (4.0)
89 (3.5)
289 (11.4)
281 (11.1)
195 (7.7)
483 (19.0)
409 (16.1)
387 (15.2)
597 (23.5)
579 (22.8)
503 (19.8)
479 (18.9)
568 (22.4)
519 (20.4) 608 (23.9)
2
3
4
1 Mains terminals
3 Motor terminals
2 Brake or regen terminals
4 Ground terminals, M10 nut
Illustration 23: E2h Terminal Dimensions (Front View)
Electrical Installation
Operating Guide | VLT® Refrigeration Drive FC 103
AQ275652766279en-000101 / 130R0707
48 | Danfoss A/S © 2020.01
