Table 6: LCP Indicator Lights
Callout Indicator LED Function
D1 On Green Activates when the drive receives power from the mains voltage or a 24 V external supply.
D2 Warn. Yellow Activates when warning conditions are active. Text appears in the display area identifying the
problem.
D3 Alarm Red Activates during a fault condition. Text appears in the display area identifying the problem.
E. Operation keys and reset
The operation keys are found toward the bottom of the local control panel.
Table 7: LCP Operation Keys and Reset
Callout Key Function
E1 [Hand On] Starts the drive in local control. An external stop signal by control input or serial communication overrides
the local [Hand On].
E2 Off Stops the motor but does not remove power to the drive.
E3 Reset Resets the drive manually after a fault has been cleared.
E4 Auto On Puts the system in remote operational mode so it can respond to an external start command by control
terminals or serial communication.
3.6 LCP Menu
Quick Menus
The Quick Menus mode provides a list of menus used to configure and operate the drive. Select the Quick Menus mode by pressing the
[Quick Menus] key. The resulting readout appears on the LCP display.
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Illustration 6: Quick Menu View
Q1 My Personal Menu
The Personal Menu is used to determine what is shown in the display area. Refer to 3.5 Local Control Panel (LCP). This menu can also
show up to 50 pre-programmed parameters. These 50 parameters are manually entered using parameter 0-25 My Personal Menu.
Product Overview
Operating Guide | VLT® Refrigeration Drive FC 103
AQ275652766279en-000101 / 130R0707| 19
Danfoss A/S © 2020.01
