Q2 Quick Setup
The parameters found in the Q2 Quick Setup contain basic system and motor data that are always necessary for configuring the drive.
See 6.3.3 Entering System Information for the set-up procedures.
Q3 Function Setups
The parameters found in the Q3 Function Setups contain data for fan, compressor, and pump functions. This menu also includes
parameters for LCP display, digital preset speeds, scaling of analog references, closed-loop single zone, and multizone applications.
Q4 Smart Setup
Q4 Smart Setup guides the user through typical parameter settings used to configure 1 of the following 3 applications:
• Mechanical brake.
• Conveyor.
• Pump/fan.
The [Info] key can be used to see help information for various selections, settings, and messages.
Q5 Changes Made
Select Q5 Changes Mode for information about:
• The 10 most recent changes.
• Changes made from default setting.
Q6 Loggings
Use Q6 Loggings for fault finding. To get information about the display line readout, select Loggings. The information is shown as
graphs. Only parameters selected in parameter 0-20 Display Line 1.1 Small through parameter 0-24 Display Line 3 Large can be viewed. It
is possible to store up to 120 samples in the memory for later reference.
Table 8: Logging Parameter Examples
Q6 Loggings
Parameter 0-20 Display Line 1.1 Small Reference [%]
Parameter 0-21 Display Line 1.2 Small Motor Current [A]
Parameter 0-22 Display Line 1.3 Small Power [kW]
Parameter 0-23 Display Line 2 Large Frequency
Parameter 0-24 Display Line 3 Large kWh Counter
Main Menu
The Main Menu mode is used to:
• List the parameter groups available to the drive and drive options.
• Change parameter values.
Product Overview
Operating Guide | VLT® Refrigeration Drive FC 103
AQ275652766279en-000101 / 130R0707
20 | Danfoss A/S © 2020.01
