Page 22
Site requirements
Operating environment
• Relative humidity: 20% to 80% non-condensing
• Temperature: 60° F to 95° F (15° C to 35° C)
Electrical requirements
• The power supply is rated at 100-240 VAC, 50-60
Hz, 1.8 amp. (It adjusts to any power within this
range.)
• Single phase, 3-wire, grounded receptacle only.
Physical requirements
• The printer weighs less than 11.5 pounds (5.3 kg).
The weight depends on the supplies and options
installed.
• Printer dimensions are 21.5 inches (546 mm) long, and 7.8 inches (198 mm) wide. The 100-card input hopper
is 9.5 inches (241 mm) high and the 200-card hopper is 11.9 inches (302 mm) high.
• The clearances required are 1 inch (25 mm) at the back, 2 inches (51 mm) on the left side, and 10.5 inches
(267 mm) above the printer latch to open the cover.
