Page 28
Use the USB port and a wired print server
1 Connect the print server to the printer using a USB
cable.
2 Connect the print server to the network using an
Ethernet cable. See the setup information provided with
the print server.
3 Follow the instructions provided with the print server to
set it up on the network, and then see "Set the Data
Format" on page 34.
Tips for Success
• Be sure to record the print server name or IP address,
which you need to send print jobs from a PC. Work with
your network support personnel if needed to obtain the
print server name and IP address.
• You do not need to perform the steps in "Set up the
network printer" on page 30. Instead, set up the print
server on the network (step 3 above).
