DataCard SD160 Installation And Administrator's Guide

SD160/SD260 Installation and Administrator’s Guide 7
Prepare the Printer to Use Rewritable Cards
1. Opentheprintercoverandremovetheprintribboncartridge.
2. Removetheprintribbonfromthecartridgeandsetitaside.
3. Makesurethatthecleaningrollerwiththereplaceablecleaningsleeveisinstalled.
4. Returntheprintribboncartridgetotheprinter.
5. Closetheprintercover.Pressdownonthe
ridgesonthefrontofthecovertomakesurethat
itlatchescompletelyonbothsides.
6. Haverewritablecardsavailabletoinsertintotheprinter.
Toprintrewritablecards,youalsomustdothefollowing:
 EnablerewritableprintinginPrinterManager.
Usetherewritablecardsettingstoenabletherewriteoptionandspecifythevaluestouse.
Referto“Print”onpage 44forcompleteinformationaboutthePrinterManagersettings.
 SpecifyrewritablecardsettingsintheCardPrinterDriver.
ForcompleteinformationaboutsettinguptheCardPrinterDrivertoprintrewritablecards,
refertoyourprinter’sDriverGuide.
Whenyouprintrewritablecards,insertthecardsoneatatime.Makesurethatthe
cardisengagedinthepickrollers.Theerase/rewriteprocesscancausethecardsto
bendslightly,whichmaypreventthemfrombeingpickedfromtheinputhopper.

DataCard SD160 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50/60 Hz
Card Capacity	100 cards input hopper, 25 cards output hopper
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Support	Windows 7, Windows 8, Windows 10
Card Thickness	0.020" to 0.030" (0.51 mm to 0.76 mm)
Print Speed	Up to 150 cards per hour (YMCKT)
