Magnetic Stripe Design
Theprinter’smagneticstripemoduleallowstheprintertoprocessmagneticstripedata.There
aretwomagneticstripeconfigurationoptions:ISOandJIS.UsethePrinterConfigurationLabel
(describedintheprinter’sUser’sGuide)todeterminethetypeofmoduleinstalled.
Magnetic Stripe Data Formats
Themoduleformat(ISOorJIS)definesthetypeandformatofthe
informationtoencode.ThestandardISOformat(alsoknownasIAT)is
athree‐trackoption.TheJISformatisasingle‐trackoption.Both
formatsincludedefaultdat asettingsthatdeterminehowmany
characte rscanbeencoded
oneachtrack,andwhichcharacterscan
beencoded.
Yourcardscanusethedefaultformatforeachtrack,orcanusea
differentcombinationoftracksanddataformats.
Three-Track Option (ISO/IAT)
Thedefaultdataformatsforathree‐trackmagneticstripeoptionare:
 Track1—IATA
 Track2—ABA
 Track3—TTS
ThiscombinationisoftenabbreviatedIAT.ThisformatisalsocalledISOformat.
IATA(InternationalAirTransportAssociation)
ThemaximumnumberofcharactersforIATAformatdatais76characters.Thesecharacterscan
includespaces,uppercasealphabeticcharacters(A–Z),numericcharacter s(0–9),andthe
followingspecialcharacters:
!
#$%'()*+,‐./;:<@>=^]\["&_
ABA(AmericanBankersAssociation)
ThemaximumnumberofcharactersforABAformatis37characters.Numericcharacters(0–9)
andthefollowingspecialcharactersareallowed:
:;<
=>
TTS(ThriftThirdStandard)
ThemaximumnumberofcharactersforTTSformatis104characters.Numericcharacters(0–9)
andthefollowingspecialcharactersareallowed:
:;<=>

DataCard SD160 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50/60 Hz
Card Capacity	100 cards input hopper, 25 cards output hopper
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Support	Windows 7, Windows 8, Windows 10
Card Thickness	0.020" to 0.030" (0.51 mm to 0.76 mm)
Print Speed	Up to 150 cards per hour (YMCKT)
