DataCard SD160 Installation And Administrator's Guide

62 Printer Manager
Maintenance Menu
TheMaintenancemenuallowsWebUserandWebAdminaccess‐leveluserstorunacleaningcard
fromPrinterManager.Additionally,theMaintenancemenuprovidestheWebAdminlevelwith
therightstouploadupdatestotheprinter.
Cleaning
Cleanstheprinterusingacleaningcard.
1. Removethesupplies.
a. Opentheprinter’stopcoverandremovetheribboncartridge.
b. Removeanyblankcardstockfromtheinputhopper.
c. Closetheprintercover.
2. Placetheunwrappedcleaningcardinthecardinputhopper.
3. SelectMaintenance>Cleaning.
4. SelectPrinterCard.
5. ClickRuntostartthecleaningprocess.PresstheUSERbuttonontheprinterwhenthe
message“17 2:Insertcleaningcard”displaysontheLCDpanel.
Theprinterpicksthecleaningcard,movesitthroughtheprinterseveraltimes,andejectsitin
theoutputhopper.
MaintenanceMenu
Option Function WebUser WebAdmin
Cleaning Cleantheprinter Runcard Runcard
Updates Updatetheprintersettings No UploadFile

DataCard SD160 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50/60 Hz
Card Capacity	100 cards input hopper, 25 cards output hopper
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Support	Windows 7, Windows 8, Windows 10
Card Thickness	0.020" to 0.030" (0.51 mm to 0.76 mm)
Print Speed	Up to 150 cards per hour (YMCKT)
