Print Ribbon
Printribbonkitsareavailablefromyourdealer.Kitsincludeaprintribbon,acleaningcard,anda
replaceablecleaningsleeve.Forbestresults,runacleaningcardandreplacethecleaningsleeve
witheachnewprintribbon.
Color Print Ribbon
Colorprintribbonisavailableineitherfull‐panelorshort‐paneloptions.Bothfull‐paneland
short‐panelprintribbonsusethefollowingcolorpanels:Y(yellow),M(magenta),C(cyan/blue),
K(black),andT(topcoat).Ribbonswithanultravioletfluorescent(F)panelprovideanadditional
securityfeature.
Full-Panel Color Print Ribbon
Usefull‐panelprintribbonwhenthecarddesign
callsforcolorprintingontheentirecard.
Full‐panelcolorprintribbonwithanultraviolet
(UV)fluorescentpanel,YMCKFT,alsoisavailable.
Short-Panel Color Print Ribbon
Useshort‐panelprintribbonwhenonlyaportionofthecard
designcallsforcolor.Forexample,acarddesignmayhavea
colorphotoonthetoporleftofthecard,andblacktextonthe
bottomofthecard.Thecolorareaforshort‐panelribbonis

either1.57inches(40mm)or1.47inches(37.5mm),dependingontheribbonconfiguration.The
ymcpanelsofshort‐panelribbonareapproximatelyhalfthelengthofafullcard.
Whenyouprintwithshort‐panelprintribbon,youdefinethelocationofthecolorareainthe
card
design.ColorprintingbeginswhentheCardPrinterDriverdetectsacolorpixeland
continuesforthelengthoftheymcpanels.
 Thecolorandmonochromeprintribbonsthataresupportedaredeterminedby
theprintermodelanditsoptions.Someribbonsmaynotbeavailableforall
printers.Contactyourdealerforcompleteinformationwhenorderingribbonsfor
yourprinter.
 Ifyourprinterrequiressupplieswitharegioncode,ref ertotheprinterLCDpanel
toseethecorrectregioncodeforyourprinter.
TheribbonpanelconfigurationthatsupportsYMCKFTfunctionalitycandiffer
dependingonyourprintermodel.

DataCard SD160 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50/60 Hz
Card Capacity	100 cards input hopper, 25 cards output hopper
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Support	Windows 7, Windows 8, Windows 10
Card Thickness	0.020" to 0.030" (0.51 mm to 0.76 mm)
Print Speed	Up to 150 cards per hour (YMCKT)
