DataCard SD160 Installation And Administrator's Guide

46 Printer Manager
Changethesettingsasneeded,andthenclickSetCurrenttoapplythechanges.
 CardRegistration—Setthestartinglocationoftheprintedarea.Thevaluesareinmm
(1mm=0.0394in).Thesettingspecifiesthedistancetomovethecardbeforeprinting.
 Increasethevaluetomoveprintingclosertothecard’sleadingedge.
 Decreasethevaluetomoveprintingawayfromthecard’sleadingedge.
45)RewritableCardEnable Disabled Disabled
46)RewritableCardType MitsubishiBlue30 MitsubishiBlue30
47)RewritableErasePasses 1 1 None [1–4
48)RewritableErasePower 0 0 Special [‐100–100]
49)RewritableWritePower 0 0 Special [‐100–100]
50)SettingsGroupPurpose Print Print None
51)TPower 00Special[‐100–100]
52)TPowerDuplex 00Special[‐100–100]
53)TWhiteShade 0 0 Shades [‐100–100]
54)TrailTrim 1.27 1.47 mm [0–5.08]
55)
VerticalOffset 17 17 dots [‐100–100]
56)YMCPower 030 Special [‐100–100]
57)YMCPower600 00 Special [‐100–100]
58)YMCPowerDuplex 00 Special [‐100–100]
59)YMCPowerNosRGB ‐48 ‐48 Special [‐100–100]
60)YMCWhiteShade 00 Shades [‐100–100]
Description DefaultValue CurrentValue(unit)
Allowed
Range

DataCard SD160 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Connectivity	USB 2.0
Power Requirements	100-240 VAC, 50/60 Hz
Card Capacity	100 cards input hopper, 25 cards output hopper
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Support	Windows 7, Windows 8, Windows 10
Card Thickness	0.020" to 0.030" (0.51 mm to 0.76 mm)
Print Speed	Up to 150 cards per hour (YMCKT)
