GBT/GM4500 TECHNICAL SPECIFICATIONS
PRODUCT REFERENCE GUIDE
299
GBT/GM4500 TECHNICAL SPECIFICATIONS
Table 27 GBT/GM4500 Technical Specifications
ELECTRICAL CHARACTERISTICS
Power Supply
GBT/GM4500:
5V to 14V +/-5% in the Communication Port
5V to 14V +/-5% in the Aux Power Port
NOTE: Aux Power Port is recommended when long cables are con-
nected to Communication Port.
Consumption
(Typical)
Gun Only: 330 mA @ 3,7V (operative)
base station Only: 80 mA @ 5V (operative)
base station with Gun in Charge (scan while charging):
475 mA (PC host USB)
1150 mA (5V on Aux Power Port)
520 mA (12V on Aux Power Port)
Gun Charging via micro USB:
480 mA (PC host port, no scan)
900 mA (wall adapter, no scan)
1160 mA (wall adapter, scan while charging)
Reading Indicators
Top and rear illumination, Good Read Spot, Beep, Vibration
Battery Capacity
Li-Ion 3.6V, 3250 mAh (11.7W/h)
Recharge Time
(Typical)
Values valid for a fully depleted battery
USB Only:
11h (no Scan)
15h (Scan while Charging)
Using Aux Power Port:
3h (no Scan)
3.5h (Scan while Charging)
Using micro USB (wall adapter):
2h (no Scan, with Wall Adapter)
4.6h (no Scan, with PC Host)
OPTICAL CHARACTERISTICS
Optical Format
1/4"
Active Imager Size
3896 um (H) x 2453 um (V)
Active Pixels
1280 H x 800 V
Illumination System
LED source
Warm White Emission (wavelength = 350 - 770 nm)
Hyper Red Emission (wavelength = 660 nm, DGM model only)
IEC 62471 Exempt Risk Group
Ambient Light Up to
100,000 lux
Tilt Tolerance
a
0° - 360°
Pitch Tolerance
a
+/- 65°
