COMMON READING CHARACTERISTICS
PRODUCT REFERENCE GUIDE 301
COMMON READING CHARACTERISTICS
Table 28 Reading Characteristics
READING CHARACTERISTICS
SR HD
DOF
a
a. All labels grade A, typical environmental light, 20°C, label inclination 10°
Code 39 5 mils: 7.0 to 38.0 cm / 2.7 to
14.9 inch
Code 39 10 mils: 2.2 to 58 cm / 0.8 to
22.8 inch
Code 39 20 mils: FOV lim. - 110 cm /
up to 43.3 inch
Code 39 3 mils: 5.0 to 15.0 cm / 2.0 to
5.9 inch
Code 39 5 mils: 0.5 to 25.0 cm / 0.2 to
9.8 inch
Code 39 10 mils: 0.5 to 45 cm / 0.2 to
17.7 inch
EAN/UPC 7.5 mils: 9.0 - 30.0 cm / 3.5 to
11.8 inch
EAN/UPC 13 mils: 1.0 - 71.0 cm / 0.4 -
27.9 inch
EAN/UPC 7.5 mils: 2.0 - 23.5 cm / 0.8 to
9.2 inch
EAN/UPC 3 mils: 1.0 - 40.0 cm / 0.4 -
15.7 inch
PDF417 6.6 mils: 6.5 to 24 cm / 2.6 to
9.4 inch
PDF417 10 mils: 2.5 to 41 cm / 1.0 to
16.1 inch
PDF417 15 mils: 2.3 to 65.0 cm / 0.9 to
25.6 inch
PDF417 4 mils: 3.0 to 12.0 cm / 1.2 to
4.7 inch
PDF417 6.6 mils: 0.5 to 23.5 cm / 0.2 to
9.2 inch
PDF417 10 mils: 0.5 to 31.0 cm / 0.2 to
12.2 inch
Data Matrix 10 mils: 5.5 to 27 cm / 2.2
to 10.6 inch
Data Matrix 15 mils: 2.8 to 41.0 cm /
1.1 to 16.1 inch
Data Matrix 5 mils: 5.5 to 9.0 cm / 2.2
to 3.5 inch
Data Matrix 10 mils: 0.2 to 27.0 cm /
0.1 to 10.6 inch
Resolution
(Maximum)
1D Min = 4 mils
PDF417 Min = 5 mils
Data Matrix Min = 7.5 mils
1D Min = 3 mils
PDF417 Min = 3 mils
Data Matrix Min = 4 mils
