RS-232/USB-COM SETTINGS ENTER/EXIT PROGRAMMING MODE

PRODUCT REFERENCE GUIDE

ACK Character

This setting specifies an ASCII character or hex value to be used as the ACK character.

ASCII characters or any hex value from 0 to 0xFF can be selected. See "

ACK Character" on

page 268

for more detailed programming instructions.

NAK Character

This setting specifies an ASCII character or hex value to be used as the NAK character.

ASCII characters or any hex value from 0 to 0xFF can be selected. See "

NAK Character" on

page 269

for more detailed programming instructions

NOTE: Setting to previously defined characters such as XON, XOFF, or host

commands conflicts with normal operation of these characters. 8-bit data

is not recognized when the option "

Data Bits" on page 38 has been set as 7

Data Bits.

Select ACK Character Setting

$CR2AC

Make a mistake? Scan the CANCEL bar code to abort

and not save the entry string. You can then start

again at the beginning.

CANCEL



0x06 ‘ACK’ Character

NOTE: Setting to previously defined characters such as XON, XOFF, or host

commands conflicts with normal operation of these characters. 8-bit data

is not recognized when the option "

Data Bits" on page 38 has been set as 7

Data Bits.

Select NAK Character Setting

$CR2NA

Make a mistake? Scan the CANCEL bar code to abort

and not save the entry string. You can then start

again at the beginning.

CANCEL



0x15 ‘NAK’ Character

Datalogic Gryphon 2D Series User Manual
