REPLACING THE BATTERY PACK
PRODUCT REFERENCE GUIDE 21
3. Insert the new battery in the same position.
4. Replace the battery holder cap, plug in the connector and return the contacts cir-
cuit to its previous location.
5. Insert the cover in the handle and screw it into place.
NOTE: When inserting the new battery into the handle, take care to position
the battery and the connector as illustrated above.
