256 GRYPHON™ I GD/GBT/GM4200
USER INDICATIONS FOR GD4200
Table 30 User Indications for GD4200
USER INDICATIONS FOR GBT/GM4200 (GUN ONLY)
Table 31 User Indications for GBT/GM4200 Gun
STATUS 3GL AND GOOD READ LED
Power-up OFF
USB Enumeration Phase
250 ms ON ↔ 250 ms OFF
USB Suspend Depends on Power Cable and specific configurations
Idle OFF
While Reading OFF
Decode Done
Solid ON
Programmable Duration (1 s default)
Reader Disabled (POS)
Communication with host not
established
100 ms ON ↔ 900 ms OFF
Firmware Upgrade
250 ms ON ↔ 250 ms OFF
Host Download
250 ms ON ↔ 250 ms OFF
Enter Service Mode No Effect
Label Programming No Effect
STATUS 3GL AND GOOD READ LED BATTERY LED
Power-up OFF OFF
USB Enumeration Phase
250 ms ON ↔ 250 ms OFF
OFF
USB Suspend
Depends on Power Cable and specific
configurations
OFF
Idle OFF OFF
While Reading OFF OFF
Decode Done
Solid ON
Programmable Duration (1 s default)
OFF
Reader Disabled (POS)
Communication with host
not established
100 ms ON ↔ 900 ms OFF
OFF
Firmware Upgrade
250 ms ON ↔ 250 ms OFF
OFF
