PROGRAMMING MODE
PRODUCT REFERENCE GUIDE
259
PROGRAMMING MODE
The following indications ONLY occur when the scanner is in Programming Mode.
TROUBLESHOOTING
INDICATION DESCRIPTION LED BEEPER
Enter
Programming
Mode
A valid programming label
has been scanned.
LED blinks continu-
ously
Scanner sounds four low fre-
quency beeps.
Rejection of Label
Label has been rejected. N/A
Scanner sounds three times at
lowest frequency & current vol-
ume.
Acceptance of
Partial Label
In cases where multiple labels
must be scanned to program
one feature, this indication
acknowledges each portion
as it is successfully scanned.
N/A
Scanner sounds one short beep
at highest frequency & current
volume.
Acceptance of
Programming
Configuration option(s) have
been successfully pro-
grammed via labels and the
scanner has exited Program-
ming Mode.
N/A
Scanner sounds one high
fequency beep and four low fre-
quency beeps followed by reset
beeps.
Cancel Item Entry
Cancel label has been
scanned.
N/A
Scanner sounds two times at
low frequency & current volume.
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
Nothing happens when
the scan
button is pulled.
No power to the imager
Check system power. Ensure power sup-
ply is connected.
Interface or power cables are loose. Ensure all cable connections are secure.
LED comes on but bar
code does not decode.
Imager not programmed for correct bar
code type.
Ensure imager is programmed to read
the type of bar code scanned. Refer to
the PRG for more information.
Bar code label is unreadable.
Check the label to ensure it is not
defaced. Try scanning another bar code
type.
Distance between imager and bar code
is incorrect.
Move imager closer to or further from
the bar code.
Bar code is decoded but
not transmitted to the
host.
Imager not programmed for the correct
host type.
Scan the appropriate host type bar code.
Refer to the PRG for more information.
