ENTER/EXIT PROGRAMMING MODE GS1 DataBar™ Expanded Set Length 1
Product Reference Guide
179
GS1 DataBar™ Expanded Set Length 1
This feature specifies one of the barcode lengths for GS1 DataBar™ Expanded Length Control.
Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in
Fixed Length Mode. Length includes the barcode’s data c
haracters only. The length can be set
from 1 to 74 characters.
Table 16 provides some examples for setting Length 1. See page 256 for detailed instructions on
setting this feature.
Table 16. GS1 DataBar™ Expanded Length 1 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
01 Character 07 Characters 52 Characters 74 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT GS1 DataBar™ EXPANDED LENGTH 1SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘1’ ‘0’ and ‘7’ ‘5’ and ‘2’ ‘7’ AND ‘4’
5 Scan ENTER/EXIT PROGRAMMING MODE
Select GS1 DataBar™ Expanded Set Length 1 Setting
Make a mistake? Scan the CANCEL barcode to abort and not
sav
e the entry string. You can then start again at the begin-
ning.
CANCEL
DEFAULT
01 = Length 1 is 1 Character
To Next Page
