Exposure Mode

Product Reference Guide

CAMERA CONTROL

Exposure Mode

Strobed Exposure Mode:

For any selectable scanning mode, performance on moving barcodes

can be improved by flashing the scanner's lighting (strobe mode). The scanner strobes at a very

high frequency, so the change in lighting may not be apparent. When enabled, the scanner can

read codes moving at up to 1m/sec, depending on the bar size and direction the code is moving.

Continuous

DEFAULT

Strobed

Default Chapter3
