Datalogic Gryphon I GM440 Series

Technical Specifications
314 Gryphon™ I GD44XX/GBT4400/GM440X
Standard Cable Pinouts
Figure 19, Figure 20 and Table 50 provide standard pinout information for
the interface cable.
Figure 19. Standard Cable Pinouts: Handheld
Pin 10
Cable Clip (Latch)
To Host
Cable
Cable Strain Relief
Bottom of Scanner
Interface Cable Port
Pin 1
Figure 20. Standard Cable Pinouts: Base Station
4
5
7
6
3
1 2
8
The signal descriptions in Table 50 apply to the connector on the reader and
are for reference only.
